P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels
Specifications
Brand Name :
DDW OR OEM
Model Number :
FAPRO Series
Certification :
CE,ROSH,FCC,ISO9001
Place of Origin :
GuangDong
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Pixels :
P5 P6.67 P8 P10
Module size :
480*320mm
Brightness :
8000-10000nits
Refresh rate :
7680Hz
Protection degree :
IP68
Cabinet material :
Die-casting aluminum
Input Voltage :
AC100-240V, 50/60Hz
Cabinet size (WxHxD) :
960x960x100
Description

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

P10mm P8mm P6.67mm P5mm 10000nits Outdoor IP68 Waterproof Advertising 960x960mm LED Display Screen Panels

Pixel Pitch 5mm 6.667mm 8mm 10mm
Packaging method SMD 1921 Triple In - (Six Leg Lamp)
Brightness 8000cd/m2
Module resolution 96x64 Dots 72x48 Dots 60x40 Dots 48x32 Dots
Module size (WxH) 480mmx320mm
Pixel density 40000 pixels/m² 22500 pixels/m² 15625 pixels/m² 10000pixels/m²
Cabinet resolution 192x192Dots 144x144 Dots 120x120 Dots 96x96Dots
Cabinet size (WxHxD) W960mmxH960mmxD100mm
Cabinet weight 27kg/m²
Maintenance method Front and rear maintenance
Protection level Front IP68 and rear IP66
Cabinet flatness ≤0.4mm
Module/box material Aluminum/Die cast Aluminum
Module connection method Hard connection design
Module signal connection point Dual backup redundancy
Color temperature Adjustable from 2000K to 15000K
Viewing angle Horizontal>160 °, vertical>110 °
Physical contrast (black/white) 8:01 10:1 15:1 24:1
Reflective coefficient (white ratio) 12% 9% 6% 4%
Maximum power 700W/m² 650W/m² 660W/m² 590W/m²
Average power 70-180W/m² 70-180W/m² 70-180W/m² 70-180W/m²
Power parameters AC 100~240V/low voltage power supply
Grayscale 16bit
Refresh rate 7680Hz
Frame frequency 50/60 Hz
Operating temperature/humidity range -20℃~+60℃/10~90%RH
