Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Specifications
Brand Name :
RUIHUI
Certification :
CE, ISO certification
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
30 work days
Packaging Details :
Wooden Box or Vacuum Packing
Model Number :
MAC2-600
Price :
Negotiable
Stock Width(mm) :
50~600
Stock Thickness(mm) :
0.2~3.2
Line Speed(m/min) :
16~24
Coil Weight(Kg) :
3000/5000
Work Roll Number(Pcs) :
upper 6/lower 5
Main Motor(Kw) :
AC 4.5
Warranty Period :
12 Months
Automatic grade :
Automatic
Driven type :
Pneumatic,Hydraulic
Application :
Machinery & Hardware
Voltage :
220V/380V,50HZ
Colour :
Customized
Description

Automotive processing 3-in-1 servo feeder, metal uncoiler, Ruihui stamping feed line

The feeder is an indispensable equipment for automatic continuous production with a punching machine. It can reduce the production cost of stamping processing, improve the processing efficiency and improve the quality of stamped products. Therefore, it has been widely used in the stamping industry.

1. Air Feeder: This is the lowest-priced feeder equipment in the stamping industry. It uses cylinder clamps to complete the feeding action. It is easy to install and allows customers to automate with minimal investment.

2. roller feeder: no need to use additional power, gas source, the output shaft of the punching machine to provide feed power, feed speed and punch synchronization performance is good, is currently the most popular and cost-effective feeder equipment.

3. NC servo feeder: It is the first feeder model to introduce the CNC system. The servo motor drives the feeding roller to complete the feeding action. The time of relaxation and feeding is provided by the cam signal of the punching machine to achieve complete synchronization with the punching machine. Feeding accuracy Up to ±0.02mm.

It is the only feeder type in the three models that can be used for long step, multi-step, and thick plate material feeding. It has the widest range of applications and the easiest operation (just set the length and step on the touch screen). The number of times can be the highest degree of customization (can be customized thick plate, double tape, yaw type).

Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line

Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line

Specification:

Model MAC2-400 MAC2-500 MAC2-600 MAC2-800
Stock Width(mm) 50-400 50-500 50-600 50-800
Stock Thickness(mm) 0.3~3.2 0.3-3.2 0.3-3.2 -3.2
Max.Coil Weight(kg) 3000 3000 3000 5000 5000 7000
Max.Coil O.D.(mm) 1200 1200 1200
Coil I.D.(mm) 8 8 508 508
Feed Length(mm) ~500* ~500* ~500* ~500*
Max. Line Speed(m/min) 16-24 16-24 16-24 16-24
Work Roll Number(pieces) upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5
Feed Roll Number(set) 1 1 1 1
Main Motor(kw) AC2.9 AC2.9 AC4.4 AC4.4
Mandrel Expansion hydraulic hydraulic hydraulic hydraulic
Reel Motor(kw) 1.5 1.5 1.5 2.2 2.2 3.7
Power(V) 3 Phase 220V/380V/50HZ
Operating Air(Mpa) 0.49 0.49 0.49 0.49


Straigtening performance:

tock Thicknees (mm) Stock Width (mm)
0.3 400 500 600 800
0.4
0.6
0.8
1.0
1.2
1.4
1.6 470 470
1.8 400 400
2.0 360 360
2.3 300 300 300 300
2.5 230 230 230 230
2.8 150 150 150 150
3.2 110 110 110 110


*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line
Automotive Processing 3 In 1 Servo Feeder , Metal Uncoiler Stamping Feed Line

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
