Manipulator Decoiler Straightener Feeder Heavy Material Frame Non Metallic Material Processing

The heavy-duty material frame adopts the vertical material discharging and unwinding method. By placing the coil material in the expansion and contraction drum, the motor-driven speed reducer drives the expansion and contraction drum to rotate, and the contact friction between the expansion and contraction reel and the coil material is utilized. The force is used to drive the drive belt to rotate to achieve the purpose of unwinding.

In the initial stage of production, firstly, the jog operation mode is adopted, even if the heavy material frame is stopped after a short time to start, the coil material is discharged with a certain length of material, and then part of the material discharged by the coil material is pulled through various processing by manual traction. device.

Such as leveling machine, feeder, punching machine, etc., then open the heavy material frame, and the induction frame automatically controls its opening and closing, which can realize fully automatic processing and production.

However, the coils used as raw materials are not all conductive materials, and many of the raw materials produced and processed by customers are non-conductive, such as silicon steel sheets, film materials, and some non-metal materials.

At this time, if the sensor frame is still used for control during processing, the intermediate relay and time relay in the heavy-duty material rack will not jump because the material is not conductive, even if it is in contact with the sensor rack, and the stop of the material rack cannot be controlled. The rack will always be unloaded and automated unwinding is not possible.

At this time, Ruihui light-controlled heavy-duty material frame is needed, and the light-controlled heavy-duty material frame replaces the traditional contact-type sensor frame control method with the on-beam photoelectric switch.

In actual use, when the material sag is drooped to a certain extent to block the photoelectric, it will automatically control its shutdown. After the machine is used, the material will be automatically turned on and discharged when the material rises. The control is sensitive and no need to touch the material, which eliminates the problem of material scratching, and fundamentally Automatic discharge and unwinding of non-conductive materials are realized.

Products:

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
