Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Specifications
Brand Name :
RUIHUI
Certification :
CE Certificate
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
30 work days
Packaging Details :
Wooden Box or Vacuum Packing
Use :
Sheet
Voltage :
380V/Customized
Power(W) :
10KW
Dimension(L*W*H) :
1900*1250*1600
Weight :
3T
Warranty :
1 Year
Product Name :
NC Servo Straightener Feeder
Material Width :
50-400mm
Material Thickness :
0.2-3.0mm
Coil Weight :
2000kg
Work Roll Number :
Upper 4 /down 3
Feed Roll Number :
1 set
Material :
Metal
Power :
3 Phase 220V/380V/50HZ
Color :
Customized
Description

Auto Parts Stamping Processing, MAC Feeder, Material Leveling Adjustment, punch machine coil

www.ruihui.net

Ruihui feeder sets feeding, correction, material rack three-in-one automatic feeding device,Ruihui MAC feeder head debugging.
1. Feed roller pressure adjustment: By adjusting the pressure regulating valve, the upper roller and the lower roller can be prevented from slipping, and the pneumatic pressure is controlled at the same time to avoid crushing the material, causing indentation or slipping phenomenon.
2. Material offset: If the material starts to be offset incorrectly, it should be immediately confirmed whether the mold is parallel and placed in the center of the table. Whether the material enters the leveling machine at right angles and in the middle, this operation can be measured by the gage, if there is a slight irregularity You can slowly position by adjusting the left and right positions of the stopper wheel.
3. material leveling adjustment: material leveling principle: the leveling drum is arranged in a zigzag pattern, if the flattening roller on the inlet side is put down, the material is bent along the drum, if the flattening roller on the outlet side is pressed too much The material is bent downwards.
Generally, the inlet side is lowered to a position where the upper and lower flattening roll gaps are 1 to 1.5 mm smaller than the material thickness, and the outlet side is adjusted to be the same as the material gap (ordinary material).
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Specification:

ModelMAC2-400MAC2-500MAC2-600MAC2-800
Stock Width(mm)50-40050-50050-60050-800
Stock Thickness(mm)0.3~3.20.3-3.20.3-3.2-3.2
Max.Coil Weight(kg)300030003000500050007000
Max.Coil O.D.(mm)120012001200
Coil I.D.(mm)88508508
Feed Length(mm)~500*~500*~500*~500*
Max. Line Speed(m/min)16-2416-2416-2416-24
Work Roll Number(pieces)upper 6
lower 5		upper 6
lower 5		upper 6
lower 5		upper 6
lower 5
Feed Roll Number(set)1111
Main Motor(kw)AC2.9AC2.9AC4.4AC4.4
Mandrel Expansionhydraulichydraulichydraulichydraulic
Reel Motor(kw)1.51.51.52.22.23.7
Power(V)3 Phase 220V/380V/50HZ
Operating Air(Mpa)0.490.490.490.49


Straigtening performance:

tock Thicknees (mm)Stock Width (mm)
0.3400500600800
0.4
0.6
0.8
1.0
1.2
1.4
1.6470470
1.8400400
2.0360360
2.3300300300300
2.5230230230230
2.8150150150150
3.2110110110110


*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment
Auto Parts Stamping Processing MAC Coil Feeder Straightener Material Leveling Adjustment

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
