Specifications
Brand Name :
RUIHUI
Model Number :
MAC4-400
Certification :
CE, ISO certification
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
60 work days
Packaging Details :
Wooden Box or Vacuum Packing
Stock width :
20~300mm
Stock thickness :
0.3~3.2mm
Stock thickness*Stock width :
2.0*200/3.2*80
Pass line :
70~170mm
Releasing Performance :
~80
Motor :
Yaskawa
Bearing :
Japan NSK
Main Motor :
AC0.75
Condition :
New
Description
Metal Parts Stamping Die, Nc Feeder, Punch Feed Roller,feeding line,straightener feeder
www.ruihui.net

The amount and direction of feeding error are not necessarily the cause of the failure:
1. There is metal or other foreign matter entering the feeding roller or gear.
2. There is interference between the feeding cam, the relaxing cam and the timing of the punching action.
3. When the material is fed into the feeder, the roller will slip.

Corresponding troubleshooting methods:
1. Remove foreign matter from the rollers or gears.
2. Adjust the micro switch (L, S).
3. Increase the pressure of the roller.

2 times the amount of feed failure occurred:
1, often happens.
2. The punching action is once, and the feeding action is twice.

Corresponding troubleshooting methods:
1. Check if the micro switch and wire terminal of the NC feeder start to have noise interference; if there is noise interference, replace the wire between the micro switch and the terminal block.
2. Reset or replace the micro switch (L, S)
Metal Parts Stamping Die, Nc Feeder, Punch Feed Roller,feeding line,straightener feeder
The reason why the roller does not relax is:
1. The positioning guide pin in the mold is not effective.
2. The time for the feeder roller to relax is not correct.
3. There is an offset phenomenon in the feeding direction.
4, the roller does not go smoothly.
5. The micro-switch

Specification:

Model MAC4-400 MAC4-600 MAC4-800 MAC4-1000
Stock Width(mm) 70-400 70-600 70-800 70-1000
Stock Thickness(mm) 0.6~6.0 0.6-6.0 0.6-6.0 0.6-6.0
Max.Coil Weight(kg) 5000 5000 7000 7000
Max.Coil O.D.(mm) 1200 1200 1200
Coil I.D.(mm) 8 8 508 508
Feed Length(mm) ~500* ~500* ~500* ~500*
Max. Line Speed(m/min) 16-24 16-24 16-24 16-24
Work Roll Number(pieces) upper 4
lower 3		 upper 4
lower 3		 upper 4
lower 3		 upper 4
lower 3
Feed Roll Number(set) 1 1 1 1
Main Motor(kw) AC5.5 AC7.5 AC7.5 AC11.0
Mandrel Expansion hydraulic hydraulic hydraulic hydraulic
Reel Motor(kw) 2.2 2.2 3.7 3.7
Power(V) 3 Phase 220V/380V/50HZ
Operating Air(Mpa) 0.49 0.49 0.49 0.49


Straigtening performance:

tock Thicknees (mm) Stock Width (mm)
0.6-1.3 400 600 800 1000
2.0
2.3
2.5
2.8 933
3.2 714 714
4.0 457 457 457
4.5 361 361 361 361
5.0 293 293 293 293
6.0 203 203 203 203


*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Metal Parts Stamping Die, Nc Feeder, Punch Feed Roller,feeding line,straightener feeder
Metal Parts Stamping Die, Nc Feeder, Punch Feed Roller,feeding line,straightener feeder

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.

SW signal of the punching cam is not normal.
