Because the servo feeder adopts the numerical control system to accurately control the feeding roller, it has the advantages of higher feeding precision, better stability, easier operation and wider application range than other feeding devices.

1. Pneumatic NC servo feeder: This is the most used servo feeder model in the stamping industry. It uses cylinder clamping to relax, not subject to installation restrictions. It can be used not only with almost all presses, but also with hydraulic presses and shears. However, due to the use of cylinder push-pull form relaxation, there is a certain response time, so it is not suitable for high-speed feeding occasions.

2. Mechanical NC servo feeder: The mechanical rod used for relaxation mode is relaxed, the relaxation speed is fast, and the installation is limited. It is mainly used with the punching machine for short-step high-speed feeding. It is easier to relax and debug. Both mechanical NC and pneumatic NC can be used.

3. Pivot-type NC servo feeder: It is specially developed for the production and production of wafer cutting customers. It adopts Japanese imported servo and adopts computer closed-circuit feedback control to ensure the accuracy is within ±0.02mm. The material is conveyed on a two-dimensional plane, so that the wafers are rounded and rounded, and the flatness of the wafer is ensured, thereby maximizing material utilization.

4. Thick plate type NC servo feeder: It is specially developed for conveying 4.5-6mm thick plate. Compared with ordinary NC servo feeder, it not only increases the power of the motor but also the upper and lower gear teeth of the feed roller. In addition to the angle, a pair of feed rollers has been added, which fundamentally eliminates the slippage of the thick plate material conveyance and the instability is unstable.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
