When the stamping automatic production line processes the sheet, in most cases, the continuous sheet is not cut after punching. The traditional method is to manually cut the scrap and then pile it up and then dispose it as garbage, which not only causes the stamping workshop. Dirty, affecting normal production, but also greatly increased the labor intensity of operators and reduced economic benefits.

Ruihui Machinery specializes in customizing a heavy-duty material rack for winding customers. It adds a tensioning device consisting of a guide rod, a reciprocating screw, a torque motor and a control box to the standard heavy-duty material frame to tension the punching machine. The coils sent out from the discharge port ensure that the scrap is evenly and tidy.

The reciprocating screw of the customized heavy-duty material frame is directly connected with the torque motor, and the control electric box regulates the motor torque. When the winding diameter of the material holder tray is increased, the torque provided by the torque motor can be adjusted by the torque control. Winding constant tension ensures that the waste is always tightly tensioned to ensure uniform waste.

When the Ruihui custom-made heavy-duty material frame is actually used, the material frame reciprocating screw moves under the driving of the torque motor, and the cut scrap is guided by the guide rod and wound on the material holder tray.

At the same time, the reciprocating screw is driven by the motor to perform left-right translational movement and to drive the guide rod to translate left and right, so that the waste is evenly wound around the material holder tray, and four more than the standard heavy-duty material holder. The mobile casters can be changed at any time according to the actual production needs to meet the needs of diversified receipts.

Specification:

Straigtening performance:

*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
