Specifications
Brand Name :
RUIHUI
Certification :
CE Certificated
Place of Origin :
Shandong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
30 work days
Packaging Details :
Wooden Box or Vacuum Packing
After-sales Service Provided :
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty :
1 Year
Name :
NC straightener feeder
Function :
Feeding the material into the press after straighting the material
OEM & ODM :
OEM & ODM
Material Width :
500mm
Material thickness :
0.3-3.2mm
Max.Coil Weight(kg) :
3000-5000
Work Roll Number(piece) :
uppper6 / lower5
Motor Brand :
YASKAWA/MITSUBISHI/SIEMENS
Description
Plate Straightening Machine, Sheet Metal Forming, Roller Feeder Feeding Step, Automatic shearing feeder
http://www.ruihui.net

Roller feeder feeding step test method:

1. Use the inching operation to stop the punch at the bottom dead center position, mark the material, and then punch the sheet once, and mark the material.

After repeating this several times, the measurement is performed, and after comparing with the required feeding step, the adjusting screw is re-adjusted according to the demand to reach the required feeding distance.

2. Inching operation punching machine, let the punch output shaft drive the roller feeder to feed the material into the punching die, ensure that the punching machine punches the guiding hole, and then injects to the punching machine more than 3 points, the guiding pin and the guiding hole The position was compared and determined.

If the position of the guiding pin and the guiding hole are correct, it means that the step setting is correct, if it is not correct, it needs to be re-adjusted.

3. When measuring the feeding step of the roller feeder, pay special attention to the inability to use the inching operation to stop the punch at the top dead center position measurement, because when the punch slider stops at the top dead center position.

Feeding is not completed, usually only sent half, so each stop position will be different, the adjustment of the feeding step can not be measured correctly, so make sure that the punch slider stop position exceeds 3 o'clock position when measuring.

Sheet Metal Forming Plate Straightening Machine / Automatic Shearing Feeder

Specification:

Model MAC2-400 MAC2-500 MAC2-600 MAC2-800
Stock Width(mm) 50-400 50-500 50-600 50-800
Stock Thickness(mm) 0.3~3.2 0.3-3.2 0.3-3.2 -3.2
Max.Coil Weight(kg) 3000 3000 3000 5000 5000 7000
Max.Coil O.D.(mm) 1200 1200 1200
Coil I.D.(mm) 8 8 508 508
Feed Length(mm) ~500* ~500* ~500* ~500*
Max. Line Speed(m/min) 16-24 16-24 16-24 16-24
Work Roll Number(pieces) upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5
Feed Roll Number(set) 1 1 1 1
Main Motor(kw) AC2.9 AC2.9 AC4.4 AC4.4
Mandrel Expansion hydraulic hydraulic hydraulic hydraulic
Reel Motor(kw) 1.5 1.5 1.5 2.2 2.2 3.7
Power(V) 3 Phase 220V/380V/50HZ
Operating Air(Mpa) 0.49 0.49 0.49 0.49


Straigtening performance:

tock Thicknees (mm) Stock Width (mm)
0.3 400 500 600 800
0.4
0.6
0.8
1.0
1.2
1.4
1.6 470 470
1.8 400 400
2.0 360 360
2.3 300 300 300 300
2.5 230 230 230 230
2.8 150 150 150 150
3.2 110 110 110 110


*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Sheet Metal Forming Plate Straightening Machine / Automatic Shearing Feeder
Sheet Metal Forming Plate Straightening Machine / Automatic Shearing Feeder

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
