50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
Specifications
Brand Name :
RUIHUI
Certification :
CE, ISO certification
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
30 work days
Packaging Details :
Wooden Box or Vacuum Packing
Condition :
New
After-sales Service Provided :
Field maintenance and repair service, Engineers available to service machinery overseas
Product name :
NC Servo Feeder
Name :
NC Servo Feeder
Stock width :
20-1000mm
Stock thickness :
0.3-3.2mm
Releasing Performance :
-80
Motor :
Yaskawa
Bearing :
Japan NSK
Power :
3Phase 220V/380V/50HZ
Description
Belt Feeder Assembly Parts, Metal Mold Stamping Processing, Belt Feeder, Oil bath automatic feeder manufacturer
http://www.ruihui.net

The general structure of the belt feeder is mainly composed of a conveyor belt, a drum, a supporting device, a driving device, a tensioning device, a discharging device, a cleaning device and a frame.
The belt feeder is a continuous feeding machine, which uses a conveyor belt wrapped around the front and rear rollers as a traction and bearing member. The driving roller drives the belt movement by friction and runs together with animal materials. The purpose of conveying materials.
Feeder advantage features:
1. High-precision feeding: For the advent of high-tech industry, computer closed-circuit feedback control ensures accuracy within ±0.02mm.
2. Setting of feeding length: directly input the feeding length on the control panel to achieve the required feeding distance.
3. User-friendly manual mode: It can input the appropriate 3-stage manual speed, which makes it easier for the user to operate and accurately feed the material into the mold for positioning.
4. stage feeder: can input 20 groups of different feeding length, each group provides 999 times of punching, to meet the processing and production of special products (optional).
5. high efficiency relaxation device: with the cam signal of the punch and simple material thickness adjustment, you can quickly set the relaxation angle.
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
Specification:

ModelMAC2-400MAC2-500MAC2-600MAC2-800
Stock Width(mm)50-40050-50050-60050-800
Stock Thickness(mm)0.3~3.20.3-3.20.3-3.2-3.2
Max.Coil Weight(kg)300030003000500050007000
Max.Coil O.D.(mm)120012001200
Coil I.D.(mm)88508508
Feed Length(mm)~500*~500*~500*~500*
Max. Line Speed(m/min)16-2416-2416-2416-24
Work Roll Number(pieces)upper 6
lower 5		upper 6
lower 5		upper 6
lower 5		upper 6
lower 5
Feed Roll Number(set)1111
Main Motor(kw)AC2.9AC2.9AC4.4AC4.4
Mandrel Expansionhydraulichydraulichydraulichydraulic
Reel Motor(kw)1.51.51.52.22.23.7
Power(V)3 Phase 220V/380V/50HZ
Operating Air(Mpa)0.490.490.490.49


Straigtening performance:

tock Thicknees (mm)Stock Width (mm)
0.3400500600800
0.4
0.6
0.8
1.0
1.2
1.4
1.6470470
1.8400400
2.0360360
2.3300300300300
2.5230230230230
2.8150150150150
3.2110110110110


*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing
50HZ Oil Bath Automatic Feeder For Belt Feeder Assembly Parts , Metal Mold Stamping Processing

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
