Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Specifications
Brand Name :
RUIHUI
Certification :
CE, ISO certification
Place of Origin :
Shandong, China (Mainland)
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets Per Month
Delivery Time :
30 work days
Packaging Details :
Wooden Box or Vacuum Packing
After-sales Service Provided :
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty :
1 Year
Stock width :
20-100
Stock thickness :
0.1-3.2
Stock thickness*Stock width :
3.0*100/3.2*80
Pass line :
70-170
Releasing performance :
-200
Motor :
Yaskawa
Bearing :
Japan NSK
Description
CNC Feeding Machine, Auto Parts Stamping, Ruihui Punch Automatic Feeding, Direct vibration feeder, Wafer feeder
www.ruihui.net

The reasons for the inaccurate feeding of the high-speed roller feeder are:
1. The material thickness adjustment is not adjusted well, which causes the roller press material to not slip tightly. For different material thicknesses, the thickness of the feed material of the feeder should be adjusted in time.

2. When the thickness of the material is thick, the pressure spring of the roller feeder is not pressed in time, resulting in insufficient pressure of the feeding roller and slipping, so that the feeding is not accurate.

3. The brake device of the high-speed roller feeder has oil stains, resulting in brake failure, excessive brake friction, loss of friction, and need to be re-polished or replaced with new brake pads.

4. There is iron scrap foreign matter in the gear, which causes the feeding to be inaccurate.

5. The roller in the one-way clutch is worn, resulting in inaccurate feeding. It is necessary to replace the new roller. Please contact Yongsheng Machinery for replacement.

The reasons why NC feeders are not allowed to feed are:
1. The pressure of the feeding roller of the NC control feeder is insufficient, resulting in slippage and inaccurate feeding. Adjust the pressure screw to increase the roller pressure.

2. NC control feeder gear into the iron filings foreign matter, need to remove iron filings and foreign bodies, usually pay attention to cleaning and maintenance.

3. servo motor drive belt clearance is too large, you need to remove the cover to adjust the belt clearance.

4. The adjustment of the relaxation time angle is too late, causing the mold guide pin to leave the material guide hole. The roller has not pressed the material to cause the material to retreat and adjust the correct relaxation time.

5. The feeding roller enters the oil stain and causes slipping. It is necessary to clean the oil stain and keep the roller clean.

Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing

Specification:

Model MAC2-400 MAC2-500 MAC2-600 MAC2-800
Stock Width(mm) 50-400 50-500 50-600 50-800
Stock Thickness(mm) 0.3~3.2 0.3-3.2 0.3-3.2 -3.2
Max.Coil Weight(kg) 3000 3000 3000 5000 5000 7000
Max.Coil O.D.(mm) 1200 1200 1200
Coil I.D.(mm) 8 8 508 508
Feed Length(mm) ~500* ~500* ~500* ~500*
Max. Line Speed(m/min) 16-24 16-24 16-24 16-24
Work Roll Number(pieces) upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5		 upper 6
lower 5
Feed Roll Number(set) 1 1 1 1
Main Motor(kw) AC2.9 AC2.9 AC4.4 AC4.4
Mandrel Expansion hydraulic hydraulic hydraulic hydraulic
Reel Motor(kw) 1.5 1.5 1.5 2.2 2.2 3.7
Power(V) 3 Phase 220V/380V/50HZ
Operating Air(Mpa) 0.49 0.49 0.49 0.49


Straigtening performance:

tock Thicknees (mm) Stock Width (mm)
0.3 400 500 600 800
0.4
0.6
0.8
1.0
1.2
1.4
1.6 470 470
1.8 400 400
2.0 360 360
2.3 300 300 300 300
2.5 230 230 230 230
2.8 150 150 150 150
3.2 110 110 110 110

Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing
Direct Vibration High Speed Feeder With Yaskawa Motor Japan NSK Bearing

1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
