Stainless Steel Compressed Knitted Wire Mesh Filters Used As Exhaust Silencers

We supply Knitted Wire Tube Gasket Axial Compressed, also mesh washers, knitted wire mesh filters/mufflers, exhaust silencers and seals. Used mainly as auto parts for exhaust system and EMI shielding system.

Metal elastomer knitted mesh filters /gaskets obtained with the cladding of layers in concentric metallic mesh around an elastomer material that accomplishes the function of elastic recovery after compression. Various sections are available and dimensions upon client request. This type is not suitable for water tight sealing; for this specific application refer to the Twin shield type of gasket. The possibility of combining elastomer and metallic mesh and overlapping layers is very broad and left to the needs of the client.

A range of knitted wire mesh filters/gaskets, providing a cost-effective solution to high shielding performance applications in the magnetic and electrical fields RFI/EMI and including EMP. Manufactured on a circular wire knitting machine using a single wire. The mono-filament interlocking-loop construction gives strength while allowing it to conform to almost any size or shape. The manufacturing process allows for an optional elastomer core to be included in to the product to aid compression. An additional environmental seal/carrier is also an option. It is available in a variety of combinations to suit many EMC and environmental sealing applications.

Material of knitted mesh filter

Stainless steel wire 201,304,316,316L,430, brass wire, etc.
Compressed from knitted stainless steel, copper, nickel, aluminum or monel wire mesh materials.

Features

High strength and overall rigidity
Good air permeability
Excellent filtering accuracy
Good filter resistance, mechanical strength, abrasion resistance, heat resistance and cold resistance
Easy to clean, simple assembly, long replacement cycle.
Special sizes can be customized.

Applications

Knitted mesh compressed filters /gaskets and washers are mainly used for:
Oil-gas separation, air purification filters of various machinery and equipment;
Sealing, damping( shocking proof), silencers and exhaust gas purification components of auto parts;
Electronics and electrical products EMI shielding devices.
