Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass
Specifications
Brand Name :
FGG
Model Number :
FGB80
Place of Origin :
Zhejiang, China
MOQ :
2000m2
Payment Terms :
L/C, T/T
Delivery Time :
within 30 work days after receiving confirmed PI
Packaging Details :
End Cap
Product name :
FGB80
Sample :
300*300 Available
Thickness :
5-6mm
Color :
Clear
Brand :
FGG
Application :
Windows,Doors,Curtain Wall etc
Min Size :
2440*1830mm
Description

5-6mm Hard Coated Low-E Laminated with Solar Reflective CTN150 Glass for Buildings

Performance data Sheet:

Glass Make-up Visible Light (%) Solar Energy (%) Solar
Heat Gain Coefficient		 Shading
Coefficient		 U-Value (W/M2·K)
Trans-
mittance		 Reflectance Trans-
mittance		 Reflec-
tance		 Absor-
ption
Outside Inside Summer
Day
Time		 Winter Night
Time
VLT LR LR ET ER EA SHGC SC
6mm FSolar CTN150 (#2) / 1.52PVB / 6mm FGB80(#4) 44 17 23 33 12 45 0.44 0.50 2.65 3.42

Product Feature:

1. Low emissivity down to 0.15;

2. Can be used monolithically;

3. Can be tempered (flat or curved);

4. Can be laminated on #2 & #4 surface;

5. Can be insulated on #2 and/or #4 surface;

6. Can be printed;

Product Name Hard Coated Low-E FGB80
Max Size 3300mm×4880mm (Automatic line)
Min size 300*300mm
Glass thinkess 5mm-6mm
Color of the glass clear
Processing types

Common Tempered,

laminated,

tempered laminated,

Insulated glass,

ETC
Processing capacity 400 Ton / Day
Application

1. Window
2. Curtain Wall
3. Buildings

etc.

Description:

Hard coated Low-E glass is made by coating the glass with a thin metallic oxide layer at the end of tin bath during the float glass process. The coating is basically burned with the glass surface at a temperature around 600℃. The coating is durable and have long shelf-life. The emissivity of this coated glass is 0.15-0.25 and can provide energy efficient functions for windows, doors, curtain walls, etc.

Bulilding Hard Coated Solar Control Low E Glass With Solar Reflective CTN150 Glass

Founded in June 1998, FGG is a comprehensive large-scale enterprise which integrates glass R&D, manufacturing, processing and sales. The headquarters is located in Jiaxing, a core city of the Yangtze River Delta.

Our products include four categories: solar glass, high-quality float glass,architectural glass and home furnishing glass. Moreover, the Group has vertically expanded to the construction of photovoltaic power stations and quartz rock mining to form a complete industrial chain.
