High Quality 70mm Pillow Block Bearing For Attaching To The Shaft

UCP214-70mm Steel Pillow Block Bearing:

70*74.6*274mm Bearing Features:

Inner Ring Diameter (bore):70mm

Outer Ring Diameter:74.6mm

Width:274mm

Bearing Weight:6.5KG

UCP214-70mm Steel Pillow Block Bearing Description:

UCP214-70mm Steel Pillow Block Bearing:

UCP214-70mm Steel Pillow Block Bearing Description:

Diminisions:
Bore: 70mm
Bolt hole to bolt hole: 8.267 in. (210mm)
Overall length: 10.472 in. (266mm)
Shaft height: 3.126 in. (79.4mm)
Overall height: 6.102 in. (155mm)
Bolt hole: 1 in. (25mm)

The UCP214 70mm pillow block bearing unit is equipped with two specially designed setscrews positioned in the inner ring of the ball bearing to lock onto the shaft. The pillow block set screws are placed at a 90-degree angle to optimize balance between holding power and inner ring distortion. The UCP214 70mm pillow block bearings are relubricatable and offer a full-width inner ring for added stability.

The UCP214 pillow block bearing also features a positive-contact, three-piece, fiber-imbedded R-seal to protect against harmfull contaminants and retain lubricant. The setscrew locking mechanism on the pillow block bearing is easy to install and well suited for reversing applications and normal loads.
Applications for the UCP214 70mm pillow block bearing include: Construction, Conveyors, Food and Beverage, Packaging and General Industrial Equipment.

Packing Method:

We have multiple packages for shielded radial ball bearing

1. Industrial package: plastic tube + paper carton + wooden pallet

craft paper + paper carton + wooden pallet

2. Individual package: individual paper box + paper carton + wooden pallet

3. As customer's demand

Factory Photo:

Working principle:

1.Outer spherical bearing can bear radial load, radial load and axial load.

2.When it only bears radial load, the contact Angle is zero. When the deep groove ball bearing has a large radial clearance.

3.It has the performance of angular contact bearing and can bear a large axial load.
