UCP215-75mm Steel Pillow Block Bearing High Level Bearing In China

UCP215-75 Steel Pillow Block Bearing:

75*77.8*300mm Bearing Features:

Inner Ring Diameter (bore):75mm

Outer Ring Diameter:77.8mm

Width:300mm

Bearing Weight:7.3KG

UCP215-75mm Steel Pillow Block Bearing Description:

UCP215-75mm Steel Pillow Block Bearing:

High quality 75mm pillow block bearing. The bearing has a wide inner ring with two set screws for attaching to the shaft. Housing is cast iron with a grease zerk for re-lubing the bearing.

Diminisions:
Bore: 75mm
Bolt hole to bolt hole: 8.543 in. (217mm)
Overall length: 10.812 in. (275mm)
Shaft height: 3.252 in. (82.6mm)
Overall height: 6.362 in. (161.6mm)
Bolt hole: 1 in. (25mm)

The UCP215 75mm pillow block bearing unit is equipped with two specially designed setscrews positioned in the inner ring of the ball bearing to lock onto the shaft. The pillow block set screws are placed at a 90-degree angle to optimize balance between holding power and inner ring distortion. The UCP215 75mm pillow block bearings are relubricatable and offer a full-width inner ring for added stability.

UCP215-75mm Steel Pillow Block Bearing Advantages:

1. Outer spherical bearing with seat is composed of outer spherical bearing and bearing seat. There is no need to design another bearing box in use. It is small in size and simple in structure. It can be installed directly on the design part of the main engine with bolts. It is convenient to use.

2. Simple and practical

Bearing seat is integral structure, bearing capacity is large, rigidity is good, bearing and bearing seat can be interchangeable, that is, the same bearing seat can be installed with different types of bearings; similarly, the same type of bearing can choose different types of bearing seat.

3. Auto-adjustable

The outer spherical bearing with seat can work under the condition of two bearing seats with different axes, and the maximum automatic adjustment angle can reach 2 degrees.

Shipping Method:

1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc

2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping

3. For large amount (GW > 500KGS), we can send you by sea

Factory Photo:

How to Place an Order:

1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.

2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.

3. If you agree with our price, we will make proforma invoice for payment

4. After payment is done, we will start to prepare bearings and arrange shipment

Quality In Everything We Do:

Suppliers quality: working only with the best

Our Supplier Quality and Development (SQD) division guarantees the flawless supply of highest quality raw materials and components.
Process quality: accurate, on-time production

All manufacturing facilities employ a Lean approach in manufacturing, involving every team member in a philosophy of continuous improvement. We have state-of-the-art production lines in all our plants. The integrated manufacturing process controls enable us to check 100% of the parts at every critical production step.

OEM-Quality Products

We deliver our products to leading global manufacturers of transmissions, axles, differentials, and fluid pumps amongst others; these customers use our products directly or integrate them into their Original Equipment.
