Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm
Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm
Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm
Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm
Specifications
Brand Name :
DEEG
Model Number :
NU1026
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
1PC
Price :
USD0.1~99/ Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000 Piece/Pieces per Month
Delivery Time :
5-10Days
Packaging Details :
Single Box(White Box/Color Box/Wooden Box),or per your requst.
Structure :
Cylindrical Roller Bearings
Model :
NU1026
Material :
GCR15
Number Of Row :
Single Row
Rolling Element :
Cylindrical Roller
Vibration Level :
V2,V3
Description

NU1026 130*200*33mm Cylindrical Roller Bearings Steel Bearing Using Japanese Technology

130*200*33mm Bearing Features:

Inner Ring Diameter (bore):130mm

Outer Ring Diameter:200mm

NU1026 Cylindrical Roller Bearings:

Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm

NU1026 Cylindrical Roller Bearing Description:

Model Number: NU1026
Inside Diameter: 130mm
Outside Diameter: 200mm
Seal Type: Double Shielded, 2RS
Material: Chrome steel, Gcr15
Precision Rating: P0-P5
Brand: TOPE or other brands
Payment term: T/T,L/C,Western Union, PayPal
Delivery time: 1-5 days for small amout, 15-40 days for big amount


more models:

Boundary dimensions(mm) Basic load ratings(kN) Limiting speeds(rpm) Mass(Kg) Bearing Number
d D B rs min rs1 min Cr Cor Grease Oil (Approx.) PYC
25 47 12 0.6 0.3 15.1 14.1 16,000 19,000 0.092 NU1005
30 55 13 1 0.6 19.7 19.6 14,000 16,000 0.13 NU1006
35 62 14 1 0.6 22.6 23.2 12,000 15,000 0.179 NU1007
40 68 15 1 0.6 27.3 29.0 11,000 13,000 0.22 NU1008
45 75 16 1 0.6 31.0 34.0 9,900 12,000 0.28 NU1009
50 80 16 1 0.6 32.0 36.0 8,900 11,000 0.295 NU1010
55 90 18 1.1 1 37.5 44.0 8,200 9,700 0.442 NU1011
60 95 18 1.1 1 40.0 48.5 7,500 8,800 0.474 NU1012
65 100 18 1.1 1 41.0 51.0 7,000 8,200 0.485 NU1013
70 110 20 1.1 1 58.5 70.5 6,500 7,600 0.699 NU1014
75 115 20 1.1 1 60.0 74.5 6,100 7,100 0.738 NU1015
80 125 22 1.1 1 72.5 90.5 5,700 6,700 0.98 NU1016
85 130 22 1.1 1 74.5 95.5 5,400 6,300 1.03 NU1017
90 140 24 1.5 1.1 88.0 114 5,100 5,900 1.33 NU1018
95 145 24 1.5 1.1 90.5 120 4,800 5,600 1.4 NU1019
100 150 24 1.5 1.1 93.0 126 4,600 5,400 1.45 NU1020
105 160 26 2 1.1 105 142 4,300 5,100 1.84 NU1021
110 170 28 2 1.1 131 174 4,100 4,800 2.33 NU1022
120 180 28 2 1.1 139 191 3,800 4,400 2.44 NU1024
130 200 33 2 1.1 172 238 3,400 4,000 3.69 NU1026
140 210 33 2 1.1 176 250 3,200 3,800 4.05 NU1028
150 225 35 2.1 1.5 202 294 3,000 3,500 4.77 NU1030

NU1026 Cylindrical Roller Bearing Description:

1. The rolling element is a rolling bearing of cylindrical roller. Cylindrical roller bearings are separated bearings, which are very convenient to install and disassemble.


2. Cylindrical roller bearings can withstand large radial loads and are suitable for high-speed operation.

NU1026 Cylindrical Roller Bearing Advantages:

1. Cylindrical roller and raceway are linear contact bearings. Load capacity is large, mainly bearing radial load.

2. The friction between the rolling element and the retaining edge of the ring is small and suitable for high-speed rotation.

3. Generally, steel plate stamping cage or copper alloy car cage are used.

Shipping method:

1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc

2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping

3. For large amount (GW > 500KGS), we can send you by sea

Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm

Factory Photo:

Large Diameter Steel Cylindrical Roller Bearings NU1026 130*200*33mm

How to Place an Order:

1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.


2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.

3. If you agree with our price, we will make proforma invoice for payment


4. After payment is done, we will start to prepare bearings and arrange shipment

Matters needing attention :


1.Vibration can be measured by using special bearing vibration measuring device (frequency analyzer, etc.) and abnormal conditions can be inferred by frequency distribution. The measured values vary depending on the operating conditions of the bearings or the installation position of the sensors.


2.If the temperature of the bearing exceeds 125 C for a long time, the service life of the bearing will be reduced. The causes of high temperature bearing include: insufficient lubrication or excessive lubrication, impurities in bearing raceway, high limit speed, long-term overload operation of bearing, etc.

FAQ

Q: Are you a trading company or a factory?

A: We have both. We are trading company and we have own factory.

Q: What is the delivery time if we place an order?

A: For small orders, our delivery time is 3 days. If the amount is large, usually our delivery time is 7-20 days.

Q: What is your payment term?

A: We accept T/T, W/U, PayPal and L/C.

Q: Do you have a warranty on bearings?

Answer: In normal use, our bearing guarantee period is 1 year.
