Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E
Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E
Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E
Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E
Specifications
Brand Name :
DEEG
Model Number :
NJ202E
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
1PC
Price :
USD0.1~99/ Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000 Piece/Pieces per Month
Delivery Time :
5-10Days
Packaging Details :
Single Box(White Box/Color Box/Wooden Box),or per your requst.
Type :
Roller
Number of row :
Single Row
Precision rating :
P0 P6 P5 P4 P2
Seals type :
Open,ZZ,2RS
Structure :
Cylindrical
Feature :
Long Life,High Precision ; Lower noise
Description

Gcr15 Bearings Carbon Steel Bearings Cylindrical Roller Bearings NU1005 25*47*12mm

15*35*11mm Bearing Features:

d:15mm

D:35mm

B:11mm

cr:12.7KN

cor:10.4KN

NJ202E Cylindrical Roller Bearing Description:

Model Number: NJ202E
Inside Diameter: 15mm
Outside Diameter: 35mm
Seal Type: Double Shielded, 2RS
Material: Chrome steel, Gcr15
Precision Rating: P0-P5
Brand: TOPE or other brands
Payment term: T/T,L/C,Western Union, PayPal
Delivery time: 1-5 days for small amout, 15-40 days for big amount


more models:

d D B rsmin Ew Fw Mass CrKN CorKN Limiting
speed		 Bearing
Code		 D1min D1max D2min D3min D4max D5min D6max
15 35 11 0.6 30.3 19.3 0.047 12.7 10.4 22000 N202E 17.4 18.5 20 22 32.6 31 29
15 35 11 0.6 30.3 19.3 0.049 12.7 10.4 22000 NJ202E 17.4 18.5 20 22 32.6
15 35 11 0.6 30.3 19.3 0.048 12.7 10.4 22000 NU202E 17.4 18.5 20 22 32.6
17 40 12 0.6 35.1 22.1 0.068 17.6 14.6 18000 N203E 21 21.5 23 28 36 36 34
17 40 12 0.6 35.1 22.1 0.07 17.6 14.6 18000 NJ203E 21 21.5 23 28 36
17 40 12 0.6 35.1 22.1 0.069 17.6 14.6 18000 NU203E 21 21.5 23 28 36
17 40 12 0.6 35.1 22.1 0.073 17.6 14.6 18000 NUP203E 21 21.5 23 28 36
17 40 16 0.6 35.1 22.1 0.053 24 22 18000 NJ2203E 21 21.5 23 28 36
17 40 16 0.6 35.1 22.1 0.051 24 22 18000 NU2203E 21 21.5 23 28 36
17 40 16 0.6 35.1 22.1 0.055 24 22 18000 NUP2203E 21 21.5 23 28 36
17 47 14 1 40.2 24.2 0.124 25.5 21.2 16000 NJ303E 21.2 23.5 25 28 42.8
17 47 14 1 40.2 24.2 0.122 25.5 21.2 16000 NU303E 21.2 23.5 25 28 42.8
17 47 14 1 40.2 24.2 0.127 25.5 21.2 16000 NUP303E 21.2 23.5 25 28 42.8
20 47 14 1 41.5 26.5 0.112 27.5 24.5 16000 N204E 24 26 29 32 41 43 40
20 47 14 1 41.5 26.5 0.117 27.5 24.5 16000 NJ204E 24 26 29 32 41
20 47 14 1 41.5 26.5 0.114 27.5 24.5 16000 NU204E 24 26 29 32 41
20 47 14 1 41.5 26.5 0.119 27.5 24.5 16000 NUP204E 24 26 29 32 41
20 47 18 1 41.5 26.5 0.15 32.5 31 16000 NJ2204E 24 26 29 32 41
20 47 18 1 41.5 26.5 0.146 32.5 31 16000 NU2204E 24 26 29 32 41
20 47 18 1 41.5 26.5 0.154 32.5 31 16000 NUP2204E 24 26 29 32 41
20 52 15 1.1 45.5 27.5 0.156 31.5 27 14000 NJ304E 24 27 30 33 45
20 52 15 1.1 45.5 27.5 0.153 31.5 27 14000 NU304E 24 27 30 33 45
20 52 15 1.1 45.5 27.5 0.16 31.5 27 14000 NUP304E 24 27 30 33 45
20 52 21 1.1 45.5 27.5 0.219 41.5 39 14000 NJ2304E 24 27 30 33 45
20 52 21 1.1 45.5 27.5 0.215 41.5 39 14000 NU2304E 24 27 30 33 45
20 52 21 1.1 45.5 27.5 0.224 41.5 39 14000 NUP2304E 24 27 30 33 45
25 47 12 0.6 41.5 30.5 0.083 13.4 12 28000 NU1005 27 30 32 33 34
25 52 15 1 46.5 31.5 0.135 29 27.5 15000 N205E 29 31 34 37 46
25 52 15 1 46.5 31.5 0.14 29 27.5 15000 NJ205E 29 31 34 37 46
25 52 15 1 46.5 31.5 0.137 29 27.5 15000 NU205E 29 31 34 37 46
25 52 15 1 46.5 31.5 0.145 29 27.5 15000 NUP205E 29 31 34 37 46

NJ202E Cylindrical Roller Bearings:

Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E


Description:

1. The rolling element is a rolling bearing of cylindrical roller. Cylindrical roller bearings are separated bearings, which are very convenient to install and disassemble.
2. Cylindrical roller bearings can withstand large radial loads and are suitable for high-speed operation.

Features:
1. Roller and raceway are in line contact or downline contact, which has large radial bearing capacity and is suitable for bearing heavy load and impact load.
2. Small friction coefficient, suitable for high-speed, limit speed close to deep groove ball bearings.
3. N-type and NU-type can move axially. They can adapt to the change of relative position between axle and shell caused by thermal expansion or installation error. They can be used as free-end support.
4. The processing requirement of axle or seat hole is higher. The relative deviation of axle of outer ring after bearing installation should be strictly controlled to avoid the concentration of contact stress.
5. The inner ring or outer ring can be separated to facilitate installation and disassembly

Shipping method:
1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc
2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping
3. For large amount (GW > 500KGS), we can send you by sea

Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202ESingle Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E

FAQ

Q1: Are you trading company or manufacturer ?
A: We are factory and professional manufactuer of bearings.

Q2: Can I get a sample to check out the quality ?
A: Sure, free samples are available for stock products if you can payfor the shipping cost.

Q3: Can you do OEM to print my logo/brand on the products ?
A: Yes, we can print your logo/brand on the products, you just need to send us your logo/brand files, we will show you how it looks like before shipping out.

Q4: How long is your delivery time ?

A: Generally we have regular stocks for standard bearings that can be shippedin 2 days after your payment. It will take 15-35 days for new production order, which depends on your order quantity.

Single Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202ESingle Row Sealed Or Open Roller Bearing / Precision Roller Bearing NJ202E
