High Precision Ball Bearings / Combine Harvester Bearings GW209PPB2 Certified ISO9001
High Precision Ball Bearings / Combine Harvester Bearings GW209PPB2 Certified ISO9001
Specifications
Brand Name :
DEEG
Model Number :
GW209PPB2
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
1PC
Price :
USDN1/ Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000 Piece/Pieces per Month
Delivery Time :
5-10Days
Packaging Details :
Single Box(White Box/Color Box/Wooden Box),or per your requst.
Model :
GW209PPB2
Material :
GCR15
Rolling Element :
Balls
Number Of Row :
Single Row
Precision Degree :
P6,P5,P4
Feature :
High Precision
Description

Agricultural Machinery Bearing GW209PPB2 Steel Bearing CR15 Certified ISO9001

GW209PPB2 Agricultural Machinery Bearing

45.000*85.000*30.175mm Bearing Features:

Inner Ring Diameter (bore):1.7717 Inch

Outer Ring Diameter: 3.3465 Inch

Width:1.1880 Inch

Dynamic load:7350

The static load:4150

Weight:1.44KG

GW209PPB2 Agricultural Machinery Bearing Description:

Model Number GW209PPB2
Inside Diameter: 1 49/64
Outside Diameter: 3 11/32
Thickness: 1 3/16
Seal Type: Double Shielded, 2RS
Material: Chrome steel, Gcr15
Precision Rating: P0-P5
Brand: TOPE or other brands
Payment term: T/T,L/C,Western Union, PayPal
Delivery time: 1-5 days for small amout, 15-40 days for big amount

GW209PPB2 Agricultural Machinery Bearing

High Precision Ball Bearings / Combine Harvester Bearings GW209PPB2 Certified ISO9001

more models:

Bearing type Style d D Be Bi Dynamic load The static load

Weight

Lbs.
GW209PPB2 3 1.7717 3.3465 1.1880 1.1880 7350 4150 1.44
45.000 85.000 30.175 30.175
GW209PPB4 3 1.5350 3.3465 1.1880 1.1880 7350 4150 1.65
39.000 85.000 30.175 30.175
GW209PPB11 1 1.7810 85.000 0.8660 1.4380 7350 4150 1.37
45.237 85.000 22.000 36.525
GW210PPB2 3 1.9380 3.5433 1.1880 1.1880 7880 4650 1.50
49.225 90.000 30.175 30.175
GW210PPB5 3 1.7850 3.5433 1.1880 1.1880 7880 4650 1.8
45.339 90.000 30.175 30.175
GW210PP9 5 1.9450 3.5433 0.9060 1.4380 7880 4650 1.75
49.403 90.000 23.000 36.525
GW211PP2 4 2.1880 3.9370 1.3120 1.3120 9740 5850 3.00
55.575 100.000 33.325 33.325
GW211PPB2 3 2.1880 3.9370 1.3120 1.3120 9740 5850 2.62
55.575 100.000 33.325 33.325
GW211PPB8 1 2.1880 3.9370 0.9840 1.3120 9740 5850 1.85
55.575 100.000 25.000 33.325
GW211PPB9 1 2.1950 3.9370 0.9840 1.5620 9740 5850 2.02
55.753 100.000 25.000 39.675
GW211PPB10 3 1.9380 3.9370 1.3120 1.3120 9740 5850 2.26
49.225 100.000 33.325 33.325
GW211PPB13 1 1.7850 3.9370 0.9840 1.3120 9740 5850 2.02
45.339 100.000 25.000 33.325
GW211PPB14 1 2.0150 3.9370 0.9840 1.3120 9740 5850 2.00
51.181 100.000 25.000 33.325
GW211PP25 5 1.7800 3.9370 1.3120 1.7500 9740 5850 2.44
45.212 100.000 33.325 44.450
GW214PP2 4 2.7559 4.9213 1.5620 1.5620 14000 8800 4.19
70.000 125.000 39.675 39.675
GW214PPB2 3 2.7559 4.9213 1.5620 1.5620 14000 8800 3.96
70.000 125.000 39.675 39.675
GW214PPB3 3 1.9380 4.9213 1.5620 1.5620 14000 8800 4.24
49.225 125.000 39.675 39.675
GW214PPB5 2 2.7559 4.9213 1.5620 2.4380 14000 8800 4.75
70.000 125.000 39.675 61.925
GW214PPB6 1 2.6881 4.9213 1.1024 2.6875 14000 8800 5.14
68.278 125.000 28.000 68.263

GW209PPB2 Agricultural Machinery Bearing Competition Advantages:

1 .Coaxiality of the sealing contact surface means that the sealing function and service life have been significantly improved


2. The outer cover extends toward the width of the sealing ring to ensure the protection of the sealing lip against mechanical damage.


3. Galvanized inner cover and outer cover

GW209PPB2 Agricultural Machinery Bearing Applications:

1. Plough disc connection bearing


2. Tillers, tractors, lawn harvesters,


3. Balers and high-power harvesting machines


4. Such as green feed harvesters and combine harvesters

Shipping Methods:

1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc


2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping


3. For large amount (GW > 500KGS), we can send you by

High Precision Ball Bearings / Combine Harvester Bearings GW209PPB2 Certified ISO9001

Factory Photos:

High Precision Ball Bearings / Combine Harvester Bearings GW209PPB2 Certified ISO9001

How to place an order:

1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.


2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.

3. If you agree with our price, we will make proforma invoice for payment


4. After payment is done, we will start to prepare bearings and arrange shipment

FAQ:

Q: Are you a trading company or a factory?

A: We have both. We are trading company and we have own factory.

Q: What is the delivery time if we place an order?

A: For small orders, our delivery time is 3 days. If the amount is large, usually our delivery time is 7-20 days.

Q: What is your payment term?

A: We accept T/T, W/U, PayPal and L/C.

Q: Do you have a warranty on bearings?

Answer: In normal use, our bearing guarantee period is 1 year.
