16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed
16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed
Specifications
Brand Name :
DEEG
Model Number :
16006
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
1PC
Price :
USDN1/ Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000 Piece/Pieces per Month
Delivery Time :
5-10Days
Packaging Details :
Single Box(White Box/Color Box/Wooden Box),or per your requst.
Structure :
Deep Grove Ball Bearings
Material :
GCR15
Size :
30*55*9mm
Rolling Element :
Balls
Seals Type :
Rubber Seals
Number Of Row :
Single Row
Description

16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed

16006 Nonstandard Deep Groove Ball Bearings

30*55*9mm Bearing Features:

Inner Ring Diameter (bore):1.181 Inch

Outer Ring Diameter:2.165 Inch

Width:0.354 Inch

Basic Dynamic Load Rating Cr: 11.2kN

Basic Static Load Rating Cor: 6.25kN

Bearings Weight:0.085KG

16006 Ball Bearing Description:

Model Number 16006
Structure: Deep groove ball bearing
Inside Diameter: 30
Outside Diameter: 55
Thickness: 9
Seal Type: Double Shielded, 2RS
Material: Chrome steel, Gcr15
Precision Rating: P0-P5
Brand: TOPE or other brands
Payment term: T/T,L/C,Western Union, PayPal
Delivery time: 1-5 days for small amout, 15-40 days for big amount

16006 Ball Bearing

16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed

more models:

Bearing
NO.		 Boundary dimensions(mm) Load Rating(kN)

Weight

(kg)
d D B Cr Cor
16001 12 28 7 5.08 2.38 0.019
16002 15 32 8 5.60 2.55 0.025
16003 17 35 8 6.82 3.38 0.027
16004 20 42 8 7.90 4.45 0.050
16005 25 47 8 8.42 5.15 0.060
16006 30 55 9 11.2 6.25 0.085
16007 35 62 9 11.5 8.80 0.100
16008 40 68 9 12.5 10.2 0.130
16009 45 75 10 12.8 10..2 0.170
16010 50 80 10 16.2 13.2 0.180
16011 55 90 11 19.4 16.2 0.260
16012 60 95 11 19.9 17.5 0.280
16013 65 100 11 20.5 18.6 0.300
16014 70 110 13 27.9 25.0 0.430
16015 75 115 13 28.7 26.8 0.46
16016 80 125 14 33.1 31.4 0.600
16017 85 130 14 34.0 33.3 0.630
16018 90 140 16 41.5 39.3 0.850
16019 96 145 16 42.7 41.9 0.890
16020 100 150 16 43.8 44.3 0.910
16021 105 160 18 52 50.5 1.24
16022 110 170 19 57.5 56.5 1.51
16024 120 180 19 56.5 57.5 1.6
16026 130 200 22 75.5 77.5 2.4
16028 140 210 22 77.5 82.5 2.84
16030 150 225 24 84 91 3.62
16032 160 240 25 99 108 4.20
16034 170 260 28 114 126 5.71
16036 180 280 31 145 157 7.50
16038 190 290 31 149 168 7.78
16040 200 310 34 161 180 10.00

16006 Nonstandard Deep Groove Ball Bearings Applications:

1.Home appliances

2.Low noise and high speed electric motors

3.Automotive components

4.Pumps

5.Machineries

Packing Methods:

We have multiple packages for shielded radial ball bearing 16006


1. Industrial package: plastic tube + paper carton + wooden pallet
craft paper + paper carton + wooden pallet


2. Individual package: individual paper box + paper carton + wooden pallet


3. As customer's demand

16006 Nonstandard Deep Groove Ball Bearings Working Features:

1. Nonstandard deep groove ball bearing is simple in structure and easy to use.

2.The largest batch production and the widest range of applications.

3.Preferred Bearing Type for User Selection.

4.Output accounts for more than 70% of the total output of bearings.

16006 Nonstandard Deep Groove Ball Bearings Working Advantages:

1. High quality through hardened bearing steel used for basic construction.


2. Optimized raceway geometry and super finishing.


3. High precision accuracy and manufacturing consistency.


4. Proprietary high performance sealing options.


5. Premium grease as lubrication system.

Factory Photos:

16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed16006 30*55*9mm Nonstandard Deep Groove Ball Bearings SKF Steel Bearing High Speed

16006 Nonstandard Deep Groove Ball Bearings Working Advantages:

1. High quality through hardened bearing steel used for basic construction.


2. Optimized raceway geometry and super finishing.


3. High precision accuracy and manufacturing consistency.


4. Proprietary high performance sealing options.


5. Premium grease as lubrication system.
