202KRR3 Disc Harrow Bearing Agricultural Machinery Bearing Steel Retainer High Mechanical Efficiency
202KRR3 Disc Harrow Bearing Agricultural Machinery Bearing Steel Retainer High Mechanical Efficiency
Specifications
Brand Name :
DEEG
Model Number :
202KRR3
Certification :
ISO9001 , ISO14001
Place of Origin :
China
MOQ :
1PC
Price :
USDN1/ Piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100,000 Piece/Pieces per Month
Delivery Time :
5-10Days
Packaging Details :
Single Box(White Box/Color Box/Wooden Box),or per your requst.
Model :
202KRR3
Material :
GCR15
Rolling Element :
Balls
Vibration Level :
V2,V3
Bearings Weight :
0.12KG
Number Of Row :
Single Row
Description

202KRR3 Disc Harrow Bearing Agricultural Machinery Bearing Steel Retainer High Mechanical Efficiency


202KRR3 Agricultural Machinery Bearing

14.287*35.000*13.000mm Bearing Features:

Inner Ring Diameter (bore):0.5624 Inch

Outer Ring Diameter:1.3780Inch

Width:0.5120 Inch

Dynamic load:2160

The static load:1000


Weight:0.12KG

202KRR3 Agricultural Machinery Bearing Description:

Model Number 202KRR3
Inside Diameter: 9/16
Outside Diameter: 1 3/8
Thickness: 33/64
Seal Type: Double Shielded, 2RS
Material: Chrome steel, Gcr15
Precision Rating: P0-P5
Brand: TOPE or other brands
Payment term: T/T,L/C,Western Union, PayPal
Delivery time: 1-5 days for small amout, 15-40 days for big amount


202KRR3 Agricultural Machinery Bearing

202KRR3 Disc Harrow Bearing Agricultural Machinery Bearing Steel Retainer High Mechanical Efficiency

more models:

Bearing type Style Trunnion A D Be Bi Dynamic load The static load

Weight

Lbs.
202KRR3 1 9/16” 0.5630 1.3780 0.4330 0.5120 2160 1000 0.12
14.300 35.000 11.000 13.000
204KPP2 3 11/16” 0.6950 1.8504 0.5510 0.8250 2900 1000 0.34
17.653 47.000 14.000 20.955
204KRR2 1 11/16” 0.6950 1.8504 0.5510 0.8250 2900 1410 0.32
17.653 47.000 14.000 20.955
204KRRB2 2 11/16” 0.6950 1.8504 0.5510 0.8250 2900 1410 0.32
17.653 47.000 14.000 20.955
205KPP2 3 7/8” 0.8760 2.0472 0.5910 1.0000 3150 1610 0.47
22.250 52.000 15.000 25.400
205KRR2 1 7/8” 0.8760 2.0472 0.5910 1.0000 3150 1610 0.44
22.250 52.000 15.000 25.400
205KPPB2 4 7/8” 0.8760 2.0472 0.5910 1.0000 3150 1610 0.47
22.250 52.000 15.000 25.400
205KRRB2 2 7/8” 0.8760 2.0472 0.5910 1.0000 3150 1610 0.44
22.250 52.000 15.000 25.400
206KPP4** 3 1” 1.0010 2.4409 0.6299 1.0600 4370 2320 0.47
25.425 62.000 16.000 26.924
G206KPPB4* 4 1” 1.0010 2.4409 0.7087 0.9450 4370 2320 0.47
25.425 62.000 18.000 24.000
206KRR6 1 1” 1.0010 2.4409 0.6300 0.9450 4370 2320 0.75
25.425 62.000 16.000 24.000
206KRRB6 2 1” 1.0010 2.4409 0.6300 0.9450 4370 2320 0.75
25.425 62.000 16.000 24.000
G207KPPB2* 4 1 1/8” 1.1260 2.8346 0.7480 1.4840 5770 3150 1.10
28.600 72.000 19.000 37.694
207KRRB9 2 1 1/8” 1.1260 2.8346 0.6690 1.4840 5770 3150 1.10
28.600 72.000 17.000 37.694
207KRRB12 2 1 1/8” 1.1260 2.8346 0.6690 0.9840 5770 3150 0.87
28.600 72.000 17.000 25.000
GW208PPB22* 4 1 1/4” 1.2510 3.1496 0.8270 1.4380 7340 3650 1.50
31.877 80.000 21.000 36.520
W208KRRB6 2 1 3/8” 1.3760 3.1496 0.8270 1.4380 7340 3650 1.31
34.950 80.000 21.000 36.520
W208PPB16 4 1 1/4” 1.2510 3.1496 0.7090 1.4380 7340 3650 1.45
31.775 80.000 18.000 36.520
W208PP21 3 1 1/4” 1.2510 3.1496 0.7090 1.4380 7340 3650 1.45
31.775 80.000 18.000 36.520
G209KPPB2* 4 1 1/2” 1.5010 3.3465 0.7480 1.1810 7350 4150 1.26
38.125 85.000 19.000 30.000
G5209KYYB2* 1 1/2” 1.5010 3.3465 1.1811 1.2992 9330 7580 1.27
38.125 85.000 30.000 33.000
209KRRB2 2 1 1/2” 1.5010 3.3465 0.7480 1.1810 7350 4150 1.27
38.125 85.000 19.000 30.000
210PPB20 3 1 1/4” 1.2550 3.5433 0.8661 1.4350 9070 5675 2.00
31.877 90.000 22.000 36.450
210PP20 3 1 1/4” 1.2550 3.5433 0.8661 1.4350 9070 5675 2.05
31.877 90.000 22.000 36.450
G210KPPB2* 4 1 1/4” 1.5010 3.5433 0.8661 1.1811 7780 4650
38.125 90.000 22.000 30.000
GC211-32-NLC* 3 1 3/4” 1.7510 3.9370 0.9840 2.2500 9740 5850 3.35
44.475 100.000 25.000 57.150

202KRR3 Agricultural Machinery Bearing Advantages:

1.Ability to withstand sustained vibration and high impact loads

2.Well-designed and high-precision sealing concept, which can operate reliably under various weather conditions

3.Low maintenance or maintenance-free design to ensure high utilization of the machine easy to install.

4.Usually it can provide the whole unit or special design, while the structure is very simple.

202KRR3 Agricultural Machinery Bearing Features:

1. High quality through hardened bearing steel used for basic construction.


2. Optimized raceway geometry and super finishing.


3. High precision accuracy and manufacturing consistency.


4. Proprietary high performance sealing options.


5. Premium grease as lubrication system.

Shipping Method:

1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc


2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping


3. For large amount (GW > 500KGS), we can send you by sea

Our Factory Photo:

202KRR3 Disc Harrow Bearing Agricultural Machinery Bearing Steel Retainer High Mechanical Efficiency

Working Principle:

1.Agricultural Machinery Bearing can bear radial load, radial load and axial load.

2.When it only bears radial load, the contact Angle is zero. When the deep groove ball bearing has a large radial clearance.

3.It has the performance of angular contact bearing and can bear a large axial load.

How to place an order:

1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.


2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.


3. If you agree with our price, we will make proforma invoice for payment.


4. After payment is done, we will start to prepare bearings and arrange shipment.


FAQ:

Q: Are you a trading company or a factory?

A: We have both. We are trading company and we have own factory.

Q: What is the delivery time if we place an order?

A: For small orders, our delivery time is 3 days. If the amount is large, usually our delivery time is 7-20 days.

Q: What is your payment term?

A: We accept T/T, W/U, PayPal and L/C.

Q: Do you have a warranty on bearings?

Answer: In normal use, our bearing guarantee period is 1 year.
