1710-1880MHz GSM 1800MHz DCS Grid Parabolic Antenna 22dBi High Gain Point to Point Antenna Signal Repeater Booster Ampli
1710-1880MHz GSM 1800MHz DCS Grid Parabolic Antenna 22dBi High Gain Point to Point Antenna Signal Repeater Booster Ampli
Specifications
Brand Name :
Deertom
Model Number :
DT-GPA1710-1880-22
Certification :
CE,ROHS,ETC
Place of Origin :
CHINA
MOQ :
20pcs
Price :
$20-$50 per piece
Payment Terms :
T/T,WESTERN UNION,PAYPAL
Supply Ability :
500PCS PER DAY
Delivery Time :
7
Packaging Details :
NEUTRAL
Frequency :
1710-1880MHz
Gain :
22dBi
Directional :
Point to Point Directional
Description
ELECTRICAL
Model DT-GPA1710-1880-22
Frequency Range 1710-1880MHz
Gain 22dBi
Beamwidth H: 14° , E: 10°
VSWR ≤1.5
F/B Ratio ≥25dB
Polarization Vertical or Horizontal
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension 600*900mm
Weight 4kg
Mounting Kits L Bracket & U Bolts
Pole Diameter Ф33～55mm
Working Temperature -40 ~ + 60℃
Rated Wind Velocity 60m/s
