800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
Specifications
Brand Name :
Deertom
Model Number :
DT-YA824-1880-10
Certification :
CE,ROHS,ETC
Place of Origin :
CHINA
MOQ :
50pcs
Price :
$10-$20 per piece
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs per day
Delivery Time :
7
Packaging Details :
Neutral Package
Frequency :
824-960/1710-1880MHz
Gain :
10dBi or more
Type :
Dual Band Outdoor Directional
Description

800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector

ELECTRICAL
Model DT-YA824-1880-10
Frequency Range 824-960/1710-1880MHz
Gain 10dBi
Beamwidth H: 60°/50° , E: 45°/40°
VSWR ≤2.0
F/B Ratio ≥13dB
Polarization Vertical
Max power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or Customized
Antenna Dimension 810mm
Weight 0.6kg
Radome Material Aluminum
Rated Wind Velocity -40~+60℃
Elements 60m/s

800-1880MHz Dual Band Yagi Antenna Outdoor Directional 10dBi GSM Antena N Connector
