BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
Specifications
Brand Name :
SHUXIN
Model Number :
BTO-22
Certification :
ISO, PVOC,SASO,FORM A, FORM E,CO
Place of Origin :
HB
MOQ :
10 tons
Price :
USD
Payment Terms :
L/C, T/T, Western Union, MoneyGram, Trade Assurance, Paypal
Supply Ability :
Have Stock in Small Quantity
Delivery Time :
7 Working Days
Packaging Details :
Wooden Box and Wooden Pallet
Material :
Hot Dipped Galvanied Sheet
Surface Treatment :
Hot Dipped Galvanized
Type :
BTO10 / BTO12 / BTO18 / BTO20 / BTO25 CBT60 / CBT65
Razor Type :
Cross Razor
Water System :
Water Tank, PVC Water Pipe
Single package size :
20X20X5 cm
Coil Diameter :
45cm, 60cm, 80cm ,90cm etc
Description

BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall

Material:Galvanized wire, PVC coated wire, Stainless steel wire, Hot Dipped Galvanized Sheet.
Razor wire is a mesh of metal strips with sharp edges whose purpose is to prevent passage by humans.
Razor wire is much sharper than the standard barbed wire.

Applications:

Razor Barbed Wire used in mainly serves in protecting of grass boundary, railway, highway and also widely used in military, jail, industry, agriculture, animal husbandry, dwelling house, plantation for fencing.

Specification:

Reference Number

Thickness

(mm)

Wire Dia

(mm)

Bard Length

(mm)

Bard Width

(mm)

Bard Distance

(mm)
BTO-10 0.5±0.05 2.5±0.05 10±1 13± 16±1
BTO-12 0.5±0.05 2.5±0.05 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.05 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.05 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5±0.05 28±1 15±1 53+1
BTO-30 0.5±0.05 2.5±0.05 30±1 21±1 54±1
CBT-60 0.5±0.05 2.5±0.05 60±1 32±1 100±1
CBT-65 0.5±0.05 2.5±0.05 65±1 21±1 100±2

Razor Barbed Wire Coil and Unit Loops

Outside Diameter No.of Loops Standard Length Per Coil Type Notes
450mm 33 8M CBT-65 Single coil
500mm 41 10M CBT-65 Single coil
700mm 41 10M CBT-65 Single coil
960mm 53 13M CBT-65 Single coil
500mm 102 16M BTO-10.15.22 Cross type
600mm 86 14M BTO-10.15.22 Cross type
700mm 72 12M BTO-10.15.22 Cross type
800mm 64 10M BTO-10.15.22 Cross type
960mm 52 9M BTO-10.15.22 Cross type

Packing & Delivery:

1. sheet is packed by pallet or strapped into bundle.
2. sheet in carton or wooden case.
3. rolls in water-proof paper+plastic film.

BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall

Producing department:

ANPING SHUXIN MANUFACTORY CO.,LTD,established in 2013.We are located in Anping county,Hebei province.Know as the hometown of Chinese wire mesh.
We are professional manufacturer and have professional technological.
Our mainly product: Chicken Cage, wire mesh basket, wire mesh container, defensive barrier, Gabion, razor wire, and barbed wire etc.
If you want to customize,please contact us.

BTO-22 Galvanized 90cm Coil Diameter Concertina Razor Barbed Wire for Protection Wall
