Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program
Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program
Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program
Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program
Specifications
Brand Name :
SHUXIN
Model Number :
SX-Mil1 to SX-Mil19
Certification :
CE, ISO, SGS, SASO, PVOC,COC,
Place of Origin :
Hebei, China
MOQ :
10 SETS
Price :
Negotiated
Payment Terms :
L/C, T/T, Western Union, MoneyGram,Paypal, T/A
Supply Ability :
10 Pieces of 40ft container per month
Delivery Time :
15 working days
Packaging Details :
Wrapped with shrink film and packed in pallet
Name :
Procurement of Defence Barriers for UNMAS Somalia Program
Wire diameter :
4.0mm to 5.0mm
Material :
heavy Galvanized Steel Wire
Mesh Hole :
3*3'(7.62*7.62cm), 75mmx75mm
Surface :
Hot Dipped Galvanized coated
Type :
Welded Gabion, HESCO Barriers
Application :
Fence Mesh,Gabions, defense, hesco, Hesco Barriers
Processing Service :
Welding, Cutting
Feature: :
Easily Assembled
Color: :
Beige, Green
Description

Procurement of Defence Barriers for UNMAS Somalia Program

Defensive barriers For Erosion And Scour Protection

Buy High Quality Defensive Barrier Sizes,Welded Wire Mesh Gabion Defensive Bastion,

Wire diameter: 4mm, 5mm

Mesh size: 50mmx100mm, 76.2mmx76.2mm,

Panel size: 2.21mx2.13m, 1.37mx1.06m, 0.61mx0.61m, it also can be customized according to customers requirement

Geotextile: in heavy duty non-woven polypropylene

Finish: hot dipped galvanized, galfan coated

Packing: packed in pallet then wrapped with shrink film

Wire Diameter: 5.0mm (Standard), 4.0mm(Standard),
Surface treatment: Hot dipped galvanized
Mesh Hole: 76.2*76.2mm (Standard),
Processing Service: Welding, Cutting
Diameter of Spring: 4.0mm
Diameter of Joint Pin: 4.0mm
Cells per Set: 1 cell, 2 cells, 3 cells, 4 cells, 5 cells can be connect for use
Color of Geotextile: Green, Beige,
Weight of Geotextile: 300GSM (Standard)
Panel Size: 0.61x0.61m,1x1m,2.13x2.21m,other size can be produced as requested

Model Height Width Length Internal Cells
SX-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
SX-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
SX-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
SX-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
SX-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
SX-6(Mil 6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
SX-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
SX-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
SX-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
SX-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5=20 cells
SX-11(Mil 11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
SX-12(Mil 12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
SX-19(Mil 19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells

Application of Defensive Barriers:

1. Military fortifications Most armies use defense barriers to build military fortifications because they can be stacked on top of each other. You can change the width and height according to your requirements. More simple and flexible.

2. Shooting range Nowadays, many people use defense barriers to build shooting ranges because of its high defense strength and safety.

3. Flood control Defense barriers are becoming more and more popular and easy to assemble, and good permeability. Most countries near coastlines choose defense barriers as flood prevention walls. Even around the hotel, they erected protective walls.

Advantages of Defensive Barrier:

1. Removable

It is assembled by panels and spring wires, and can be folded into a whole during loading and transportation.

2. Anticorrosion

The raw material is hot-dip galvanized wire, which can be used for 10 years or more and is suitable for external protection.

3. Easy installation

When you get it, open it in a spacious place and fill it with sand and mud. Even 2-3 people can finish it.

4. Rapid displacement

When you want to use it in another place, just move it and it can be used many times.

5. Easy to repair

If a part is damaged, throw it away and connect it with a new one.

Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program

Defence 4.0mm Sand Filled Barriers For Unmas Somalia Program

Anping shuxin wire mesh manufactory Co.,Ltd.is a leading China manufacturer and exporter of military defensive barrier,gabion basket.

1. Registered capital: RMB50,100,000(about USD7,590,000)

2. Area:old factory 30000m²,new factory 36000m²

3. Employees number:288 people

4. Technicist: 8 people,we can design drawing as clients’ requirements

5. No. Of QA inspectors: 5 people

6. Annual turnover: USD15,000,000

7. Certifications: ISO9001:2008

8. Export market: South Africa, Qatar, Iraq, Australia, the united Arab emirates, the United States, Brazil,Turkey,Nigeria,Sudan,Saudi Arabia,Singapore,Philippines,Malaysia,Britain, Russia,Romania,

Turkmenistan, Colombia, Kenya, Zambia, Uganda, Algeria and so on.
