Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth
Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth
Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth
Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth
Specifications
Brand Name :
KN
Model Number :
kn-1
Certification :
COC ISO
Place of Origin :
CHINA
MOQ :
10 UNIT
Price :
pla contact us
Payment Terms :
L/C, , T/T, Western Union, MoneyGram
Supply Ability :
100 unit per 15 days
Delivery Time :
20 work days
Packaging Details :
wooden pallet
Material :
Low Carbon Steel Wire, Q235
Cage Capacity :
96-128 Chickens per set
Surface treatment :
Galvanized
Cage Size :
1.98m*2.3m*1.8m
cage cells :
3 tiers or 4 tiers 4 doors
Application :
poultry farm
Type :
A type
Feature :
save space, long time life
Description

Iraq and Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth

operational principle

It is made of galvanized welded mesh, spring with other fittings, canbe filled with sand,earth,cement, stone, can be used in separate cell or some cells joint together.

HESCO barriers is a modern gabion primarily used for flood control and military fortifications.

It is made of a collapsible wire mesh container and heavy duty fabric liner,

and used as a temporary to semi-permanent

levee or blast wall against explosions or small-arms. It has seen considerable use in Iraq and Afghanistan for army and used lots of for homemade protection.


Hesco Barrier Specification

Model Height Width Length Internal Cells
KN-1(Mil 1) 54”(1.37m) 42”(1.06m) 32’9”(10m) 5+4=9 cells
KN-2(Mil 2) 24”(0.61m) 24”(0.61m) 4’(1.22m) 2 cells
KN-3(Mil 3) 39”(1.0m) 39”(1.0m) 32’9”(10m) 5+5=10 cells
KN-4(Mil 4) 39”(1.0m) 60”(1.52m) 32’9”(10m) 5+5=10 cells
KN-5(Mil 5) 24”(0.61m) 24”(0.61m) 10’(3.05m) 5 cells
KN-6(Mil 6) 66”(1.68m) 24”(0.61m) 10’(3.05m) 5 cells
KN-7(Mil 7) 87”(2.21m) 84”(2.13m) 91’(27.74m) 5+4+4=13 cells
KN-8(Mil 8) 54”(1.37m) 48”(1.22m) 32’9”(10m) 5+4=9 cells
KN-9(Mil 9) 39”(1.0m) 30”(0.76m) 30’(9.14m) 6+6=12 cells
KN-10(Mil 10) 87”(2.21m) 60”(1.52m) 100’(30.5m) 5+5+5+5+5=20 cells
KN-11(Mil 11) 48”(1.22m) 12”(0.30m) 4’(1.22m) 2 cells
KN-12(Mil 12) 84”(2.13m) 42”(1.06m) 108’(33m) 5+5+5+5+5+5=30 cells
KN-19(Mil 19) 108”(2.74m) 42”(1.06m) 10’5”(3.18m) 6 cells

Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile ClothIraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile ClothIraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth

Detail Specification

1. Wire Diameter: 4-5mm

2. Mesh Size: 3" (75x75mm,50x50mm) 80*80mm

3. Panel Size: 13 type size for any security protection,suddenly burst attacks

4. Geotextile: In heavy duty non-woven polypropylene;

5. Color: Grey and Military Green,Sand color etc.

6. Finish: Hot dipped galvanized, Galfan wire.

7. Packing: Packed in pallet

Application

1. Environmental Barriers,Flood Barriers, a reliable, easy-to-deploy and robust solution for emergency flood protection or long-term wetland restoration

2. Defensive Barriers: Protecting both military and civilian personnel in dangerous environments demands defensive solutions that are secure, reliable and readily available.

3. Protective Barriers: Protect your workforce,Create a secure refuge for your employees by
providing protection for up to eight people with Accommodation Bunker.

4. Rockface: transforms the highly effective wall into an aesthetically pleasing structure ideal for customer-facing perimeter security where a more benign appearance is required.

Iraq And Afghanistan Military Barrier Welded Wire Mesh Hesco Defensive Barrier With Geotextile Cloth
