Dental Cavitron Ultrasonic Scaler Piezo Touch Control with Water Bottle and LED

Features

Rate input:220V 50Hz

Output Power:38VA

Fuse of main unit:T0.5AL 250V

Primary tip vibration excursion ＜90μm

Tip vibration frequency:28kHz+_3kHz

Water entrance pressure:0.01MPa~0.5MPa

Handpiece model:HP-5L with LED lamp

Function setting: G,P,E

Touch control :YES

Water bottle:with

Compatible Brand: EMS

Working Condition:

1 Product introduction

The product is used for teeth cleaning and also an important device for teeth disease prevention and treatment. The Ultrasonic
scaler is composed of main unit, handpiece, cable, water pipe, tip, torque wrench, foot switch, and power supply.
The ultrasonic scaler has following features:
1.1.1Detachable handpeice can be autoclaved under 134 °C and 0.22 Mpa.
1.1.2Automatic frequency tracking ensures that the device always works on the best frequency, stable and efficient
performance.

1.2 Contraindications;

1) The hemophilia patient is forbidden to use this equipment.
2) The patients or doctors with heart pacemaker are forbidden to use this equipment.
3) The heart disease patient, pregnant woman and children should be cautious to use the equipment.
1 3 Equipment safety classification
1) Operating mode: Continuous operation
2) Type of protection against eletric shock: Class II
3) Degree of protection against electric shock: Type B applied part
4) Applied part of the equipment Tip
5) Degree of protection against harmful ingress of water: Ordinary equipment
6) Degree of protection against harmful ingress of water: protection degree against water (used on foot switch ):IPX1
7) Degree of safety of application in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide:
Equipment can not be used in the presence of a fammable anesthetic mixture with air or with oxygen or nitrous oxide
1.4 Model and technical Parameters
