X Ray Machine Dental X Ray Tube High Performance 2mA X 70kV Max Current
X Ray Machine Dental X Ray Tube High Performance 2mA X 70kV Max Current
Specifications
Brand Name :
SAILRAY
Model Number :
KL27-0.8-70
Certification :
SFDA
Place of Origin :
CHINA
MOQ :
10PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000PCS/MONTH
Delivery Time :
30DAYS
Packaging Details :
50PCS PER CARTON
Equivalent to :
CEI OX70-M
Nominal Tube Voltage :
70KV
Nominal Focal Spot :
0.8
Target Angle :
19°
Exposure rating :
840W
Max. Current :
2mA X 70kV
Warranty :
18 months
Tube current :
8mA
Price :
Negotiation
Description
KL27-0.8-70 Stationary Anode X-ray Tube for dental x-ray machine
Quick Detail:

Model: KL27-0.8-70

Equivalent to: CEI OX70-M

Integrated high quality glass tube

Maximum Tube Voltage:70Kv

Maximum power (at 1.0s):840 W

TECHNICAL DATA

Nominal Tube Voltage 70kV
Nominal Inverse Voltage 85kV
Nominal Input Power(at 1.0s) 840W
Max. Current Continuous Service 2mA x 70kV
Max. Anode Cooling Rate 140W
Max. Anode Heat Content 7kJ
Filament Characteristics Ifmax 2.1A,2.85±0.5V
Nominal Focal Spot 0.8 (IEC60336/2005)
Target Angle 19°
Target Material Tungsten
Cathode type W filament
Permanent Filtration Min. 0.5mmAl/50 kV(IEC60522/1999)
Dimensions 72mm length by 30mm diameter
Weight 90 grams

X Ray Machine Dental X Ray Tube High Performance 2mA X 70kV Max Current

X Ray Machine Dental X Ray Tube High Performance 2mA X 70kV Max Current

For more type of our x-ray tube, please see the following chart:

BRIEF SPEC.OF STATIONARY ANODE X-RAY TUBE
Type Equivalent Nominal Focal Spot Value

Max

Rating

(W)

Max.

Voltag

(kV)

 Filament Characteristics

Target

Angle

( °)

Anode

Heat

Content(KJ)

 Dimension

Length

×Diameter
KL1-0.8-70 CEI OX/70-P 0.8 840 70 2.2A 3.6V 19 7 80×30
KL11-0.4-70 Toshiba D-041 0.4 430 70 3A 3.2V 12 4.3 67×30
KL12-1.5-85 1.5 1800 85 2.5A 2.8V 23 10 105×30
KL27-0.8-70 CEI OX/70-M 0.8 840 70 2.1A 2.8V 19 7 72×30
XD2-1.4/85 1.5 1800 85 2.6A 3.0V 23 10 105×30
XD3-
3.5/100		 2.6 3500 100 4.5A 7V 19 30 180×51
XD3A-
3.5/105X		 CEI OX105-4 2.6 3500 100 4.5A 7V 19 30 178×51
