PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting
Specifications
Brand Name :
ChuangWei
Model Number :
CWVC-5S
Certification :
CE Certification
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Supply Ability :
30 sets per month
Packaging Details :
plywooden case
Payment Terms :
T/T
Delivery Time :
10 days
Type :
Laser Cutting
Laser Power :
10W
Color :
White
Warranty :
1 year
Advantage :
oversea installation and training is available
Samples :
available for trial cutting
Cutting stress :
no
Laser pcb depaneling :
could be customized make
Description

PCB Depaneling Laser Cut Circuit Board,CWVC-5S Feature:

1. High precision CCD automatic positioning, automatic focusing. Fast and accurate positioning, save time and no worries.

2. Friendly interface,Simple operation, easy to use, free application; Small size, Save more space; rigorous security design;

3. Reduce energy consumption, Cost savings.

4. Cost-effective, fast cutting speed, stable performance

PCB Depaneling Laser Cut Circuit Board,CWVC-5S Specification:

Parameter

Technical parameters

 Main body of laser 1480mm*1360mm*1412 mm
Weight of the 1500Kg
Power AC220 V
Laser 355 nm
Laser

Optowave 10W(US)
Material ≤1.2 mm
Precisio ±20 μm
Platfor ±2 μm
Platform ±2 μm
Working area 600*450 mm
Maximum 3 KW
Vibrating CTI(US)
Power AC220 V
Diameter 20±5 μm
Ambient 20±2 ℃
Ambient ＜60 %
The Machine Marble

PCB Depaneling Laser Cut Circuit Board

PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting

PCB Depaneling Laser Cut Circuit Board Machine Principle

PCB Depaneling Laser Cut Circuit Board with No Cutting Stress for LED Lighting


PCB Depaneling Laser Cut Circuit Board Machine Application:

FPC and some relative materials;

FPC/PCB/ Rigid-Flex PCB cutting, Camera module cutting;

Our Service:

# 1 day delivery
# 24 hours fast response
# Largest manufactory in South China
# 100% responsible for quality
# 14 years experience
# Oversea installation and training is available
