Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck
Specifications
Brand Name :
DFSK
Model Number :
K01/K01L/K02
Place of Origin :
Chongqing, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
70000 units per year
Delivery Time :
10-15 working days
Packaging Details :
By Container
Product Name :
DFSK K01 K01L K02
Size :
3960*1560*1825 mm
Track Front/Rear :
1310/1310 mm
Fuel :
Gas/Petrol
Engine model :
DK13
Maximum speed :
100 km/h
Displacement :
1293 ml
Maximum power :
68 kW
Maximum torque :
125 N.m
Body color :
Elegant white/crystal silver
Full interior style :
Black interior
Description

Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck


Specification

Model name

 2024 K01 1.3L Basic 2024 K01L 1.3L Basic 2024 K02 1.3L Basic

Basic parameters

Number of Crew Members (People)

 2 5

Emission standards

 Country VI Country VI Country VI

Outline size: length * width * height (mm)

 3960*1560*1825 4435*1560*1825 4600*1560*1840

Carton size: length * width * height (mm)

 2260*1440*340 2700*1440*370 2000*1440*370

Wheelbase(mm)

 2515 2760 2760

Track Front/Rear (mm)

 1310/1310

Kerb weight(kg)

 880 910 990

Total mass(kg)

 1770 1920 1990

Engine model

 DK13 DK13 DK13
Engine type Inline four-cylinder, four-stroke, water-cooled, electronically controlled fuel-injected gasoline engine

Displacement (ml)

 1293 1293 1293

Maximum power (kW)

 68 68 68

Maximum torque (N.m)

 125 125 125

Fuel tank capacity(L)

 50

Combined fuel consumption (L/100km)

 6 6 6

Gearbox type

 Five-speed/manual

Maximum speed (km/h)

 100 100 100

Body form

 Load-bearing body

Drive mode

 Mid-mounted rear drive

Braking device

 Front disc rear drum, dual-circuit hydraulic brake
Front and rear suspension MacPherson independent suspension with front overhang, leaf spring non-independent suspension with 5 pieces at the rear

Turn to form

 Mechanical steering (○Optional electronic assistance)

Tire model

 165R14

Primary configuration

Body color

 Elegant white/crystal silver

Steel wheel decorative covers

 ● ● ●

New styling front face

 ● ● ●

Steel wheels

 ● ● ●

Front/rear fenders

 ● ● ●

Electrically adjustable headlights

 ● ● ●

Front fog lights

 ○ ○ ○
Rear suspension six-leaf leaf spring non-independent suspension - ○ ○

corrugated container

 - ● ●

Rear fence

 ○ ○ ○

Full interior style

 Black interior

Main drive visor

 ● ● ●

Electronic instrument

cluster

 ● ● ●

ESC radio

 ● ● ●

Ashtrays

●

 ● ●

Cigarette lighter

 ● ● ●

Anti-lock braking system (ABS/EBD)

 ● ● ●

Electric assist

 ○

MP5+Reversing video

(Screen)

 ○

Front door power

windows

 ○

Key fob

(with central lock)

 ○

Single steam

air conditioner

 - ○ ○

"●" - indicates that this configuration is available, "○" - indicates that this configuration is optional

DFSK K01 K01L K02 Features

Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck

Dongfeng Xiaokang K01/K01L/K02 DK13 Engine

  • Dongfeng xiaokang K01,K01L,K02 mini truck has DK13 engine, maximum power 68kW, maximum torque 125Nm
  • Sleeve chain drive, timing chain drive with high efficiency and long life.
  • PDA controllable combustion technology improves engine performance, fuel consumption is only 6L per 100km, fuel saving is more ​ efficient, economical and more environmentally friendly.

​Dongfeng Xiaokang K01 K01L K02 Model Gasoline Crew Cab Cargo Van Pickup Truck

Bearer upgrade
The third generation chassis design technology, the reinforced design of seven vertical and two horizontal directions ensures that it can be installed,

stable and does not deform.
Reinforced sub-beam design, with a thickness of 170mm and a width of 79.82mm, greatly improving the load-bearing capacity
