9mm 12mm 16mm Face Discharged Diamond Core Bits CDDA DCDMA Crealius
9mm 12mm 16mm Face Discharged Diamond Core Bits CDDA DCDMA Crealius
9mm 12mm 16mm Face Discharged Diamond Core Bits CDDA DCDMA Crealius
9mm 12mm 16mm Face Discharged Diamond Core Bits CDDA DCDMA Crealius
Specifications
Brand Name :
Yaheng
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
usd dollar 300~450 per piece
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
1000 piece per month
Delivery Time :
5~8 days after payment
Packaging Details :
Sea or Air standard packing
Product name :
Diamond Core Bit Set
Diameter Protect :
Natural Diamond
Bit Body :
Carbon Steel
Design :
Face Discharged
Style :
surface set
A-Gauge Core Bits :
AQ, AQ-RSG, AWG(AX), AWM, AWT, LTK48
Description

Ultramatrix Diamond Core Bit Set HQ 24 MM - Stage 2 UMX Bit for granite

Description:

UMX diamond bits have revolutionized mineral exploration. UMX bits drill faster, last longer, and perform in a wider range of drilling conditions and formations. The extended range and versatility of the UMX diamond bits means less tripping out rods and more core in the box.

1) certifacation Iso 9001:2008

2) with very small high quality synthetic diamonds mixed.

3) impregnated core bits are more economical to use than other bits.

4) can drill a broad range of geological formations from the softest to the hardest rock

5) widely used in all kinds of drillings for prospecting, water and electricity building and construction industry of road, railway, bridge and building taking out core to examine stake

Dimensions of Core Bits:

"Q" series: AQ, BQ, NQ, HQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT
A-Gauge Core Bits: AQ, AQ-RSG, AWG(AX), AWM, AWT, LTK48
B-Gauge Core Bits: BQ, BQ-RSG, BQ-2.400, BQ3, BWG(BX), BWM, BWT, LTK60, TBW
N-Gauge Core Bits: NQ, NQ-RSG, NQ-3.032, NQ2, NQ2-RSG, NQ3/NQTT, NQ3-RSG, NQ3-3.032, NMLC, NWG(NX), NWM, NWT, TNW,
H-Gauge Core Bits: HQ, HQ-RSG, HQ-3.830, HQ-3.895, HQ3/HQTT, HQ3-RSG, HQ3-3.895, HMLC, HWF-Long, HWF-Short, HWG(HX), HWT
P-Gauge Core Bits: PQ, PQ3, PWF-Long, PWF-Short
S-Gauge Core Bits: SWF-Long, SWF-Short
U-Gauge Core Bits: UWF-Long, UWF-Short
Z-Gauge Core Bits: ZWF-Long, ZWF-Short
T Series: T36, T46, T56, T66, T76, T86, T101
TT Series: TT46, TT56, TT66, TT76, TT86, TT101
T2 Series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
TB Series Metric Core Bits: TB36, TB46, TB56, TB66, TB76, TB86, TB101
T6 Series Metric Core Bits: T6-76, T6-86, T6-101, T6-116, T6-131, T6-146
T6S Series Metric Core Bits: T6S-76, T6S-86, T6S-101, T6S-116, T6S-131, T6S-146
B Series(IS03552-1)Metric Core Bits: B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
All other standard: CDDA, DCDMA, Crealius, and ISO sizes.

Notice:

To select the right bit for the job, assess the speed and power of your drill for the size and depths of the holes to be drilled and assess ground conditions such as rock type/formation and down-hole conditions.

Size:
bits are available in all standard drilling sizes. Also, non-standard sized bits can be produced according to requirements from clients.



Crown Height:
offers crown impreg depths of 9mm, 12mm, and 16mm .The taller crown heights provide improved bit stability and reduced vibrations, enhancing bit life and performance.



Waterways:
Various waterways are available for diamond impregnated bits. Differing waterways allow for better flushing in various ground conditions and drilling systems.


Matrix:
ROSCHEN impregnated bits matrices can be selected by our engineer according to ground conditions at client's work site.

Threads:

standard Q threads as well as thread types required by clients are available.

ABOUT US:

Wuxi Yaheng Geological Equipment Technical Co.,Ltd is a professional diamond tools manufacturer in China.

We specialize manufacturing core drilling tools and diamond tools ,core drills ,core drill rods,wireline core drill parts ect.

Yaheng 's products are widely used in geological and mineral,metallurgy,mining and hydrology industries.

Yaheng's egineers are good at making research and development,and we also have a good sales team which is professional and active service.
