Wireline Core Barrel Head Assembly BQ NQ HQ PQ Customized Diamond Overshot Tool
Wireline Core Barrel Head Assembly BQ NQ HQ PQ Customized Diamond Overshot Tool
Specifications
Brand Name :
Yaheng
Model Number :
Overshot
Place of Origin :
China
MOQ :
1
Price :
us dollar 200~350 per set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
2 days
Packaging Details :
Wooden case
Processing Type :
Casting
quality :
Premium
Material :
Carbon Steel
Color :
Customized
Length :
1.5m or 3m
Size :
BQ NQ HQ PQ
Description

Wireline Coring Barrel overshot assembly BQ NQ HQ PQ AQU BQU NQU HQU Ezy Lock

Description:

Ezy Lock Overshot

Overshot is a necessary device in wireline drilling. It's dropped on a cable and directly couples onto and lift up the inner tube assembly, eliminating the need to couple and uncouple the rod string each time the core is retrieved.

Ezy Lock Overshot is a modified product based on compact overshot. It protects against accidental release of the core barrel. This is ideal for suface application when hoisting above ground.

Features:

• Ezy Lock Sleeve provides a quick, one-handed rotation of the sleeve to lock the lifting dogs.
• Quick Release Safety Pin locks the overshot head to the spearhead point.


Specifications:

Drilling Tools/Overshots

1. A necesary device in wireline drilling
2. Lifts up the inner tube assembly directly

Specifications

Accessories of Over Shot

QTY per set

Eye Bolt

1

Cable Swivel Collar

1

Thrust Bearing

1

Castle Nut

1

Cotter Pin

1

Grease Fitting

1

Cable Swivel Body

1

Jar Staff

1

Jar Tube

1

Hex Nut

1

Cap,Ezy Lock O/shot

1

Spring,Eay Lock O/shot

1

Sleeve,Ezy Lock O/shot

1

Compression Spring

2

Steel Ball

2

Ezy Lock overshot head

1

Lifting Dog

2

Plain Pin

1

Spring Pin

1

Locking Pin

1

Set Screw

1

Locking Sleeve

1

1) Strong magnetic field and strong attractive force .

2) Have multiple Functions .

3) Be convenient and safe in use .

4) Advanced designs and multiple choices.

Description:

Brief Introductions of overshot :

The overshot is used when wear and other mechanical damage prevent the use of the regular pulling tool . We can produce overshots assembly of all wireline and Chinese standards .

Our overshots are consisted of lifting dogs , jar tube and swivel.Owing to large amount of stocks,the products can be shipped out immediately according to your requirements .
