230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade
Specifications
Brand Name :
Johnson Tools
Model Number :
230mm
Certification :
SGS, GB
Place of Origin :
China
MOQ :
50 pcs
Price :
Negotiate
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
1000pcs per month
Delivery Time :
20-35days
Packaging Details :
white or colored package
Outer Diameter :
230mm
Center hole :
16mm, 20mm, 22.23mm, 25.4mm, 50mm, 60mm, 80mm
Segment thickness :
2.6mm
Segment height :
7/10/12mm
Colour :
Clear Or As Your Request
Description

1. Description of 230mm Laser Welded Cured Concrete Cutting Blade

9" Laser welded Diamond Blade designed for angle grinder. Wet or dry cutting for no reinforcement concrete pipe, roads, highways, driveways, sidewalks and some types of brick and pavers and so on.

230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade

230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade

2. Specification of 230mm Laser Welded Cured Concrete Cutting Blade

Diameter:230mm
Segment thickness:2.6mm
Segment height:7/10/12mm
Inner hole:16/20mm, 22.23mm, 25.4mm, 50mm or as your request

Inch Diameter
(mm)		 Teeth length
(mm)		 Teeth thickness
(mm)		 Teeth height
(mm)		 Teeth number
(nos)
9" 230 37 2.6 7 16
9" 230 37 2.6 10 16
9" 230 37 2.6 12 16


Other size Concrete Saw Blade we could do as following

Inch Diameter
(mm)		 Teeth length
(mm)		 Teeth thickness
(mm)		 Teeth height
(mm)		 Teeth number
(nos)
4" 105 32 2.2 7/10/12 8
4.5" 115 31 2.2 7/10/12 9
5" 125 31 2.2 7/10/12 10
6" 150 34 2.2 7/10/12 11
7" 180 34 2.4 7/10/12 14
8" 200 40 2.4 7/10/12 13
10" 250 40 2.6 10/12/15 16
12" 300 40 3.0 10/12/15 20
14" 350 40 3.2 10/12/15 24
16" 400 40 3.4 10/12/15 28
18" 450 40 3.6 10/12/15 32
20" 500 40 4.0 10/12/15 36
24" 600 40 4.4 10/12/15 42
26" 650 40 4.4 10/12/15 42
28" 700 40 5.0 10/12/15 40
30" 750 40 5.0 10/12/15 46



3. Packing and Shipping

230mm Diamond Concrete Saw Blades / Laser Welded Cured Concrete Cutting Blade

4. About us

our company, johnson tools manufactroy co.,td have around 17years on producing diamond tools for stone and construction indrustries.
Our engineers have more experience. As a direct manufacturer, we will try our best to provide the most suitable products to you.
