Specifications
Brand Name :
JINGTE
Model Number :
FM-25
CertifiCaterion :
ISO/TS16949
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD 19800 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 piece per month
Delivery Time :
15day
Packaging Details :
neutral packing with wooden box, or as requested
Material :
Cast iron
Function :
multi function excavator
Type :
mini excavator
Moving :
diesel engine
Color :
yellow & black
AppliCaterion :
narraw area
Description

1t 1.8t 2t 2.5t 3t Garden Farm Digger Hydraulic Crawler Mini Excavator Machine


1.Product Description

1).The widened track shoes guarantee low ground pressure, high stability, and powerful traction to fulfill precise horizontal operations.
2).The wet type steering clutch and brake can prolong the service life and are interlinked with each other toguarantee the rapid and flexible
steeringcontrols by joysticks.
3). It can complete the digging, handling, and landfill operations of earthworks and is suitable for the engineeringconstructionsfor roads, farms, waterconservancy projects, municipal projects, and energy projects.
4). small hydraulic excavator boasts small size, flexible operation, and favorable trafficability, and it can work freely at small and narrow place. Usually, the excavator is applied in urban construction, landscaping, and irrigation and water conservancy etc.
5). High-end Configuration and Superexcellent Quality, High-quality Driving Experience, Solidity, High Efficiency, and Durability, Convenient and Efficient Repair and Maintenance. Optional Configuration - we uphold the " All-in-one " philosophy.


2. Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
6)We also have 0.8 ton , 1 ton,, 1.8 ton, 2 ton,2.5 ton and 3.0 ton mini Excavator for you too choose!

3. Professional Garden Tool Mini Hydraulic Excavator

ENGINE
Emission Standard Euro 5 /EPA4
Make FEIMA
Model FM-25
Power /Rotation speed 18kw(19HP)@2200rpm
Number of cylinder 3
TRACK SYSTEM
Maximum Travel speed 3.5km/h
Width of track shoe 230mm
PERFORMANCE PARAMETER
Standard Bucket capacity 0.07m³
Swing speed 9 rpm
Max. Grade ability 35°
Maximum Bucket digging force 18KN
Maximum Arm digging force 11KN
Hydraulic system pressure 21.5Mpa
Machine weight 2000kg
MACHINE SIZE
Overall dimension (L*W*H) 3555mm*1300mm*2290mm
Axle base(Track length on ground) 1230mm
Track gauge 760mm
Min.Ground clearance 150mm
Swing radius at tail 650mm
WORKING RANGE
Maximum Digging height 3700mm
Maximum Dumping height 2440mm
Maximum Digging depth 2400mm
Maximum Vertical digging depth 2025mm
Maximum Digging radius 4040mm
Minimum swing radius 1610mm
Maximum Lifting height of blade 240mm
Maximum Cutting depth of blade 270mm
Boom swing angle(Left) 75°
Boom swing angle(Right) 45°

4. Deliver time: Normally ready goods in stock

Port: Tianjin, CN

5. Payment term: 30%TT in advance, 70% against the copy of B/L

2.5t 1 Ton Mini Excavator Favorable Trafficability Mini Crawler Excavator
