1500RPM Diesel Power Generator Set 80KVA China Generator Price 3 Phase Generator
1500RPM Diesel Power Generator Set 80KVA China Generator Price 3 Phase Generator
1500RPM Diesel Power Generator Set 80KVA China Generator Price 3 Phase Generator
1500RPM Diesel Power Generator Set 80KVA China Generator Price 3 Phase Generator
Specifications
Brand Name :
SHX
Model Number :
SYF80
Certification :
ISO9001:2015, CE, TUV, BV
Place of Origin :
Foshan, China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
80 sets per month
Delivery Time :
15 working days
Packaging Details :
Standard export packing
Product name :
80KVA Yuchai Generator
Color :
Green
Frequency :
50Hz
Voltage :
400/230V
Phase No. :
3
Engine brand :
Yuchai
Alternator brand :
Faraday
Control Panel :
Smartgen HGM6110N
Description

50Hz 3 Phase Diesel Power Generator Set 80KVA China Yuchai Engine Generator

Genset Data: 400/230V, 50Hz, 3 Phase 4 Pole, 1500RPM, Power Factor 0.8.

Product Description:


1. Prime power 80KVA, standby power 88KVA.
2. Powered by Yuchai engine.
3. Original Faraday alternator.
4. Delixi air breaker.
5. Electric start with batteries.
6. Smartgen controller.

7. ATS is for option.

Generator Information:

Product Name 80KVA Diesel Genset Model SYF80
Rated Power 64KW / 80KVA Standby Power 70KW / 88KVA
Engine Brand YUCHAI Alternator Brand FARADAY
Voltage 400/230V Current 115A
Frequency 50Hz Running Speed 1500RPM
Phase 3 Power Factor 0.8
Dimension 1700×720×1200 mm Weight 720 KG

Engine Information:

Diesel Engine
Brand YUCHAI
Model YC4A110Z-D20
Engine type 4 cylinders in Line, 4 stroke, direct injection
Aspiration Turbocharged
Rotating speed 1500 RPM
Engine cooling system Water-cooled
Speed governing system Electronic speed governor
Starting method By 12V battery
Engine filter system Dry type air filter ,fuel filter, oil filter, water filter
Displacement(L) 4.214
Bore×Stroke(mm) 108×115
Compression ratio 17.5:1
100% Load fuel consumption (l/h) ≤15.1
Lube capacity(L) 11-13

Alternator Information:

Alternator
Brand FARADAY
Model FD2DS1-4
Excite type Brushless self-excited AVR regulation
Connecting type 3 phase 4 pole
Steady frequency change 0.50%
No load voltage ≥95%-105%
Steady voltage ≤±1%
Insulation class Class H
Protection grade IP23

Manufacturing Standards:

ISO8528; ISO1105; ISO3046; GB/T2820; GB755; BS5000; NEMAMG-22; YD/T502

Electrical Parameters


Wave distortion: <10%
Voltage fluctuation: <0.5%
Voltage / frequency fluctuation: <=0.5%
AVR self-regulated, voltage regulation rate: <=+- 1%
Radio interference restraining accords with stipulation of VDE0875-N and ISO8528


Control Function


Key start / auto start
Monitoring meters: Current; Frequency; Wire Voltage; Genset KVA; Genset KW; Output
Capacity; Output KW.H; Power Factor.
Warning/Shutdown: Alternator Under/Over Volts, Frequency; Under/Over Speed; Low Oil Pressure; High Engine Temp; High/Low Battery Volts; Over Current; Earth Fault Shutdown.

Now Sunkings Electric Co., Ltd. Product Lline Covers:

1. Open type gensets.

2. Silent type gensets.

3. Trailer mounted gensets.

4. Fuel tanks

5. Industrial Silencers and other genset accessories.
