3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A
3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A
3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A
3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A
Specifications
Brand Name :
SHX
Model Number :
SCE500B
Certification :
ISO9001:2015, CE, TUV, BV
Place of Origin :
Foshan, China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
80 Sets per month
Delivery Time :
20 working days
Packaging Details :
Standard export packing
Product type :
Open skid
Color :
Green
Cooling method :
Water cooled
Speed governing :
Electronic
Starting method :
Electrical start by 24V batteries
Engine brand :
Cummins
Alternator brand :
Engga
Control mode :
Manual/auto
Description

3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A

Features

  1. Universal design and manufacture
  2. Most widely used around the world
  3. With most service terminals
  4. Engineers are familiar with Cummins powered gensets
  5. You could find spare-parts very easy

Genset Specifications:

Genset model SCE500B
Genset rated power 400KW/500KVA
Rated voltage 400/230V (adjustable)
Rated current 900 Amps
Frequency 50 Hz
Power factor 0.8 Lagging
Connecting type 3 phase 4 wire
Cooling system Closed cycle water-cooled with fan, water tank
Overall dimension (L×W×H) mm 3300×1250×1850
Gross weight (kg) 4670
Diesel Engine
Brand CUMMINS
Model KTA19-G3A
Engine type 6 cylinders in Line,4 stroke, direct injection
Aspiration Turbocharged and air-to-air aftercooled
Rotating speed 1500 RPM
Engine cooling system Water-cooled
Speed governing system Electronic speed governor
Starting method By 24V batteries
Engine filter system Dry type air filter ,fuel filter, oil filter, water filter
Displacement(L) 19
Bore×Stroke(mm) 159×159
Compression ratio 13.9: 1
100% Load fuel consumption (l/h) ≤95.1
Lube capacity(L) 38
Alternator
Brand ENGGA
Model EG315-400N
Excite type Brushless self-excited AVR regulation
Connecting type 3 phase 4 pole
Steady frequency change 0.50%
No load voltage ≥95%-105%
Steady voltage ≤±1%
Insulation class Class H
Protection grade IP21

INSPECTION AND TEST

1 GENERAL

1.1 Each engine shall be tested at manufacturer’s workshop to certify the engine output and fuel consumption in accordance with the site operating condition specified by purchaser on the specification datasheet.

1.2 All relevant information drawings pertinent to the testing and test procedure shall be transmitted to the purchaser in advance of the test date notification.

1.3 The purchaser shall call for additional testing if test results are unsatisfactory or marginal. Any equipment rejected shall be repaired or replaced to the purchaser’s satisfaction and tests shall be repeated.

1.4 Any unsatisfactory material, equipment, installation, or workmanship shall be replaced or repaired to the purchasers satisfaction at the manufacturers cost.

1.5 The engine and generator shall be tested individually in accordance with relevant standards specified above.

1.6 The completed and individually tested engine and generator shall be assembled onto the base plate with all auxiliaries, instruments and controls for a complete test of the generator set.

OEM Service:

Sunkings Electric Co., Ltd. Can provide professional OEM Service for customers.

  1. Unique design and manufacture of generator according to customers requirement.
  2. Customer logo printing or painting on the genset.
  3. Installation and Operation manual neutral or headings can be design according to customer requirement.
  4. Full warranty cover to support the customers.

Picture show:

3 Phase 4 Wire Open Diesel Generator 400KW / 500KVA Cummins KTA19-G3A
