Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley
Specifications
Brand Name :
electric transfer cart on rails for steel mill transport
Model Number :
electric transfer cart on rails for steel mill transport
Certification :
CE ISO SGS
Place of Origin :
China(mainland）
MOQ :
1 set
Price :
USD 2000~7500 set
Supply Ability :
100 sets month
Delivery Time :
20 work days after received balance payment
Packaging Details :
trap and wooden case
Product Name :
electric transfer cart on rails for steel mill transport
Application :
Transfer Materials
Item :
Cart
Color :
Customized
Material :
Q235
Capacity :
1-200T
Description

Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley

Introductions
PERFECT's heavy duty electric transfer trolley are movable platforms used for the horizontal movement of materials, assemblies and other items. It is powered by storage battery, which is installed on the transfer carts. The transfer trolleys are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. Usually the heavy loads electric transfer trolley are used to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others.These material electric transfer trolley are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.
Technical Parameter
Model 2t 20t 50t 100t 150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 450 550 650 850 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 0.8 2.5 5.5 11 15
Running Distance(m)
0-20
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.3 5.5 7.6 13.9 26
Recommended Rail Model P15 P24 P43 QU100 QU100

Yellow Heavy Duty Pipe Handling Wagon Electric Transfer Trolley

Q/A

Will A Transfer Cart Be A Good Solution?
A good question to ask since there are many material handling solutions on the market! Which one is the right choice? For starters, transfer carts are moveable platforms used for the horizontal movement of materials, assemblies, and other items. Consideration must be given to the weight of the load and the travel requirements for the application.
What Are The Advantages of Using a Transfer Cart?
For smaller loads, manual carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.
What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)
