Specifications
Brand Name :
PERFECT
Model Number :
BXC
Certification :
CE, SGS, ISO
Place of Origin :
Xinxiang, China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
75 Sets per month
Delivery Time :
45 Days
Packaging Details :
The whole cart is package with tarp, and parts will be packed by wood case
Powered Source :
Storage Battery / Lead-acid Battery
Operation Mode :
Pandent and Remote Controller and PLC
Cart Frame :
Q235B
Rail Gauge :
1435mm (Customized)
Color :
Yellow/Customized
Running Distance :
No Limited
Wheel Type :
Cast steel wheel
Safrty Device :
Buffer, Alarm light, Emergency Stop Buttons
Special Function :
Anti-Explosion, Heat-Resistant, Lifting, Dumpling
Dimension :
Customized
Description

Custom Battery Steel Coils Railway Transport Cart Railway Platform for Building Site

Preview steel coils cart

Our coil transfer cart are used to transport steel coils and pipes for metal industry. This coil transfer Cars are designed to be an extremely cost effective, safe and flexible load moving alternative.
The steel coil rail car is also called a heavy transporter, headless transporter or self-propelled modular transporter. Our coil transfer carts are specially designed for coil, pipe and other round material transportation. When the goods are loaded, we can make sure the car moves safely and the goods are in a very safe condition.

Application of Electric Railway Platform

For horizontal load transfers of a wide range of material, we have the heavy duty, high quality Transfer Cart solution you need. Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base. With four different styles and standard capacities up to 60 tons, we have the solution you need and each style can be designed for your specific application.
Steel mill: transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc
Paper roll plant: transfer paper coil Painting shops: transfer workpiece into the painting room Sand blasting room Other industries: shipbuilding, quarries, warehouses and multi-bay workshops, etc
Chemical plant: Transfer materials and large machine parts;
Building Sites: Load cement concrete and building machinery;
Port: used for the container and cargoes shuttle;

Characters of Electric Railway Platform

  • Anti-explosion
  • Anti-high temperature
  • Suitable for ferry condition
  • Apply to various occasions
  • Stable start, big starting power, small impact to the gear reducer, low voltage, long lifetime and so on.
  • It has no strict requirement for the construction of the railway
  • No limit of moving distance
  • Safe and convenient operation for there is no wire outside the car
  • Adjustable speed

Custom Battery Steel Coils Railway Transport Cart Railway Platform For Building Site

Technical Parameters of Electric Railway Platform

BXC SERIES TRANSFER CART TECHNICAL PARAMETER TABLE
Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size (mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Height(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 200 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(Km) 6.5 4.8 4 3.8 3.2
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100

Why choose us?

  • PERFECT's electric railway platforms are all by no less than 120% Load Bearing Safety test before shipping.
  • PERFECT's electric railway platforms are all trustworthy and legitimate names in the industry.
  • PERFECT's electric railway platforms are design and built meeting JB/T6127-10 and Crane Girder Standards ensure durability and long lifetime.
  • PERFECT's electric railway platforms' manufacturing capacity range from 1 ton to 300 tons.
  • All products are Crane Standard Slab Steel Beam Box Structure,safety, little table deformation and large load capacity.
  • Working normally before shipping and easy operation,No need professional training operator.
  • Heady duty packaging to provide protection during shipping.
  • More than 1000 products and 587 custom design molds accumulation,committed to meet your one-stop-shop of factory material transfer carts.
  • We offer: rail construction project design and construction CAD drawing, whole series of standard CAD rail cart drawing and operation manual.

Advantages

Low noise
It's powered by electric devices, so when you are operating it, you can't feel much noise. It causes low noise level and give workers a good working environment.
Maximum safety
We always try our best to make sure the safety of the operators and the material handled. We do care the safety of everyone involved in the job.
Easy for operation
Our vehicles are easy to drive, so as soon as you get it you will be able to use it to transport your loads. We will support you to make the best by using our products.
Easy to implement into manufacturing process
Operates on standard floors; Do not require complex or permanent installation
Suitable for All Kinds of Weight
The steering battery powered trolley is superb for handling both small and extremely huge loads for its modular fabrication and its high payloads: up to 300 ton for each trolley.

About Us

PERFECT design and manufacture virtually any type of material transfer car. Recent contracts have included bespoke ladle transfer car to cater for metallurgy use; high capacity rail cart for the transport of minerals and well wagons filled with remote controller for the safe movement of thermal product. And The material transfer cart has proven to be a huge time saver for manufacture.
