Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Specifications
Brand Name :
Coil Rail Transfer Car
Model Number :
Coil Rail Transfer Car
Certification :
CE ISO SGS
Place of Origin :
Henan China
MOQ :
1
Price :
Usd2000-6000/set
Supply Ability :
30sets/week
Delivery Time :
20 work days after received balance payment
Packaging Details :
Trap and wooden case
Product Name :
50 ton Scissor Hydraulic Lifting Coil Rail Transfer Car for Factory Steel Coils Transportation
Type :
Coil Rail Transfer Car
Material :
Carbon steel
Supply Power :
Cable drum,rail,battery,etc
Rail Inner Gauge(mm) :
1200-2000
Ground Clearance(mm) :
50
Wheel Diameter(mm) :
270-600
Max Wheel Load(KN) :
14.4-265.2
Description

Scissor Hydraulic Lifting Coil Transfer Remote control Electric Power Cart

What is Scissor Hydraulic Lifting Coil Transfer Remote control Electric Power Cart

The Scissor Hydraulic Lifting Coil Transfer Remote control Electric Power Cart is powered by battery,and the battery supply power of the scissor hydraulic lifting coil rail transfer car for factory steel coils transportation to the DC motor, which is installed inside of coil transfer car body.Through the order of start, stop,forward,back,speed governing,etc, electrical control system command the order to DC motor to drive scissor hydraulic lifting coil rail transfer car for factory steel coils transportation working.With different styles and standard capacities up to 300 tons, we have the solution you need and each style can be designed for your specific application. This kind of scissor hydraulic lifting coil rail transfer car for factory steel coils transportation can run between two perpendicular tracks or L-shape track or S-shape track or curved track.

Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
Technical Table
Model BJT-2t BJT-20t BJT-50t BJT-100t BJT-150t
Rated Load(t) 2 20 50 100 150
Table Size(mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Heigth(H) 500 600 700 1000 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 2000 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 0.8 2.5 5.5 11 15
Running Distance(m) 25 30 50 50 50
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.5 5.6 7.8 14.1 26.2
Recommended Rail Model P15 P24 P43 QU100 QU100

Use' s manual

Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car

Details

Scissor Hydraulic Lifting Remote Control 0.8kw Coil Transfer Car
