No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
Specifications
Brand Name :
PERFECT
Model Number :
battery operated transfer cart
Certification :
SGS\CE\ISO
Place of Origin :
China(Mainland)
MOQ :
1
Price :
USD3100~8100
Payment Terms :
D/P, D/A, MoneyGram
Supply Ability :
88 sets month
Delivery Time :
40 work days after received balance payment
Packaging Details :
trap and wooden case
Product Name :
battery operated transfer cart
Capacity :
Customized
Color :
customized
Running Speed :
0-50m/min(Adjustable)
Control Method :
Remote Control/Pendant
Description

No Towing Cable Heavy duty low voltage Rail transfer trolley

Descraptions

The series electric flat car is a low-voltage rail-powered electric flat car. Its working principle is to reduce the voltage of 380V power supply (three-phase or single-phase) to 36V through the ground control buck system. Feeding to the conductor rail (the conductor rail doubles as the running track of the flat car), the low-voltage power is sent to the step-up transformer on the vehicle through the conductive device of the flat car, and is boosted to 380V to drive the three-phase or single-phase capacitor motor to drive The flat car runs.

No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine

Technical Parameters for KP Series Rail Transfer Carts
ModelKP-2tKP-5tKP-10tKP-16tKP-20t

KP-
25t

KP-
30t

KP-
40t

KP-
50t

KP-
63t

KP-
80t

KP-
100t

KP-
150t

Rated Load(t)25101620253040506380100150
Table Size(mm)Length( L)20003500360040004000450045005000550056006000650010000
Width( W)1500200020002000220022002200250025002500260028003000
Heigth( H)50055055060060065065070070080090010001200
Wheel Base(mm)1200250026002800280032003200380042004300470049007000
Rail Inner Gauge(mm)1200143514351435143514351435143514351435180020002000
Wheel Diameter(mm)Ф270Ф300Ф300Ф350Ф350Ф400Ф400Ф500Ф500Ф600Ф600Ф600Ф600
Wheel Quantity4444444444448
Ground Clearance(mm)50505050505050505075757575
Max Wheel Load(KN)14.425.842.664.577.794.5110.4142.8174221.4278.4343.8265.2
Reference Weight(t)2.53.545.25.66.26.57.37.810.512.314.126.2
Recommended Rail ModelP15P18P18P24P24P38P38P43P43P50P50QU100QU100


More Details
No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
Why choose us
Henan Perfect Handling Equipment Co., Ltd is a professional & international manufacturing factory specialized in researching, developing, producing and selling material handling equipment.Based on modern plant and advanced production equipment, we can produce all kinds of handling equipment from 1-1300 tons, our main products including BDG conductor rail transfer cart, BJT cable drum transfer cart, BHX safety sliding line transfer cart, BXC battery type transfer cart, BTL towed cable type transfer cart, BP non-power type transfer cart, BQY train towed type transfer cart, BWP trackless type and special type transfer cart, such as turning, trackless,ladle, hydraulic lifting, ferry, painting room, blasting booth etc.​

No Towing Cable Heavy Duty 50m/Min Rail Transfer Trolley For Stone Mine
