Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material
Specifications
Brand Name :
electric rail transfer cart for steel mill
Model Number :
electric rail transfer cart for steel mill
Certification :
CE ISO SGS
Place of Origin :
Henan, China (Mainland)
MOQ :
1 set
Price :
USD 2000~7900 set
Supply Ability :
100 sets month
Delivery Time :
20 work days after received balance payment
Packaging Details :
trap and wooden case
Product Name :
electric rail transfer cart for steel mill
Color :
Customized
Capacity :
1-300ton
Application :
Industrial Filed
Item :
CART
After-sales Service Provided :
Engineers available to service machinery overseas
Description
Heavy load 50t Rail Transfer Trolley Battery Powered Steel Factory Scrap Material
Product Introduction
With the functions of steady traveling, poleless speed regulation, PERFECT transfer trolley is commonly applied to transfer steel ladle, scrap,aluminum ladle, lead ladle, steel slag etc. We use this kind of scrap transfer trolley to moving and transporting hot metal ladles or scrap bucket to the ingot casting machines or within the plant itself.
Generally the outer surface temperature of the scrap bucket is 200-300 degree, due to the high temperature the scrap transfer trolley should be designed with heat exposure proof device, especially to the battery, motor, reducer and electric appliance. It can avoid the transfer trolley from damaging and shortening using time. In order to avoid the scrap bucket transfer trolley broken during working, there equipped two sets driving system, if the main driving system is broken, the spare driving system can be start at the same time.

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Detailed Image

Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

parameter table
Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size (mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Height(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 200 2000
Wheel Diameter (mm) 270 350 500 600 600
Running Speed (m/min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(km) 6.5 4.8 4 3.8 3.2
Recommended Rail Model P15 P24 P43 QU100 QU100

Company and Customers' visit
Henan Perfect Handling Equipment Co., Ltd. is a professional designer of material handling equpment to meet the specific requirements of each client.Our product includes Industrial Trailers, Transfer Cars, Electric Railway Transfer Trolley, Scissor Lift Tables, Turntables and many other specialty items.Our special solution to the design of each product includes a detailed review of the client requirements, which is used to develop the Functional Specification of the product.Working closely with you, we will incorporate our years of design experience into the final design of the product to assure complete customer satisfaction.
Heavy Load 50t Rail Transfer Car Battery Powered Steel Factory Scrap Material

Q/A


What Product Handling Applications Use Transfer Carts?
1. Coils (V-Groove deck)
2. Tanks (size/stability for uniformly distributed loads)
3. Assemblies (fixture cradle) for a complete build or to send a partially completed product to the next station (tractors, heavy equipment machinery)
4. Sub-Assembly shuttle from one line to another line
5. Maintenance cart for motors and pumps
6. Equipment support (stand-off deck) for navigating loads to locations with a plant facility
7. Material shuttle for steel tubing (flat decking with guard rails)
8. Elevating platform for assembly process (integrated screw-jack table)
9. Sand casting (flat decking)

How are the transfer trolley powered?
Powered AC carts have power cable connected directly to an electrical panel, typically for carts that travel along a fixed path. Cable reels can be installed for cable management.
Powered DC carts have on-board batteries that have an average running time of 16 hours. DC battery charging units can be installed on-board for convenience. Extended battery life can be accomplished by having four batteries rather than two.
How fast can the transfer trolley travel?
Typically, transfer carts come with drive motor speed of 50 fpm (with brake). Optional consideration can be given to ordering VFD (electric car only) for soft start/stop movement. Faster travel speeds can be ordered.
How to protect the transfer trolley as the temperature of scrap bucket or ladle is so high?
The materials, driving system and electrical control of the car would be specially designed. The heat insulating material is used in the car to resist the high temperature.
