Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter
Specifications
Brand Name :
Krohne
Model Number :
Dk32 / Dk34
Certification :
CCC.CE
Place of Origin :
Germany
MOQ :
1
Price :
usd540 piece/pieces
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100
Delivery Time :
5-8 work days
Packaging Details :
carton
Product Name :
area flow meter
Output :
4…20 mA/HART
Sturdy metal design :
Sturdy metal design
Thread :
G¼, ¼ NPT, etc.
Product type :
Flowmeter
Process temperature :
-40…+200°C/ -40…+392°F
Description

Germany Krohne Dk32 / Dk34 Variable area flowmeter for low liquid and gas flows

product description

The DK32/34 is a variable area (VA) flowmeter for measuring low flow rates of liquids and gases. The tried and tested meter is particularly suitable for flow monitoring and dosing in gas analyser systems or on purge panels. Due to its robust all-metal design it can also be used in difficult process conditions with temperatures up to +200°C / +392°F or pressures up to 400 barg / 5800 psig. It is available with a metering valve as standard to accurately set the flow value.

Miniature metal tube flowmeter
DK32 | DK34 tiny flow tube flow meter with a solid, stable and reliable and the characteristics of wide application, can be used to measure gas and liquid.
The rugged all-metal design ensures its resistance to high pressure, high temperature and difficult environmental conditions. The position of the float is transmitted by magnetic induction to an analog indicator showing its measured value. No power supply required.

Specifications

Brand name Krohne
Model DK32/34
Product type Flowmeter
Product positioning For low liquid and gas flows
Measurement principles Variable area float
Measured media Gases, Liquids
Digital outputs HART®
Analogue outputs 4…20 mA
Discrete outputs Limit switches
Process temperature -40…+200°C/
-40…+392°F

  • Simple, low-cost installation: Able to measure and display without auxiliary power supply
  • Purgemeter with 2 optional limit switches for flow monitoring
  • Various stainless steel and alloy sensor materials
  • Optional surface passivation with SilcoNert®2000 for trace-level analysis
  • Ingress protection IP65/66
  • Full scale value for liquids: 1.6…150 l/h / 0.4…40 GPH
  • Full scale value for gases: 16…4,800 l/h / 0.6…170 SCFH
  • Turndown ratio 10:1
  • Maximum measuring error: ±4% (acc. to VDI/VDE 3513-2) or ±3% of full scale
  • SIL 2 conform for use in Safety Instrumented Systems (SIS)
  • Approved for hazardous areas

Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter

Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter

Krohne Dk32 Dk34 Variable Area Flow Meter HART High Accuracy Flow Meter

DK32 inlet pressure regulator
The DK 32 can be directly connected to a pressure regulator to ensure constant flow rate despite operating pressure fluctuations. DK32 horizontal connection - with valve; DK34 vertical connection - no valve available.

Chemical and other process industries

  • Additives (e.g. catalysts, tensides, foam inhibitors, emulsifiers)
  • Acids, bases, phosgene and other chloridic substances, sulphuric substances
  • Condensate and cooling water
  • Nitrogen inertisation of vessels and tanks
  • Sample flow monitoring in gas analysers
  • Gas sparging in liquids

Oil and gas industry

  • Injection skids for corrosion-, scale- and hydrate-inhibitors
  • Nitrogen, flue gases etc.
  • Sample flow monitoring in analyser systems
