Specifications
Brand Name :
None
Model Number :
FW16
Certification :
CE/ISO9001: 2000/EPA/Euro 5/SGS
Place of Origin :
Shandong, China
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/P, Paypal
Supply Ability :
5000 Units/Year
Delivery Time :
3-15 week days
Packaging Details :
Nude / Wooden Box
Transmission :
Hydraulic Transmission
Drive Type :
Internal Combustion Drive
Type :
Crawler Excavator
Customized :
Support OEM and ODM
After-sales Service :
Spare Parts
Warranty :
12 Months
Bucket Capacity :
0.1-0.5m³
Transport Package :
Nude / Wooden Box
Specification :
1600kg
Color :
Blue, Yellow, Red, Orange, Green, White
Working Hour :
2000h
Description

Hydraulic Excavator Construction Diggers 1.6t Mini Excavator For Sale

Which has a unique advantage of this below point:

1. Imported famous brand Japan engine and hydraulic system with 1-year global warranty.

2. Self-produced working equipment, upper carriage, and undercarriage, heat treatment with high rigidity

3. Smooth working performance with high work efficiency.

4. Competitive market price with high reliability and best after-sale customer service.

5. Real warranty supplied by the original manufacturer for a whole year.

6. More than 10 years experiences of manufacturing time and exporting time.

Specifications:

Specifications
Overall Dimension (L*W*H)/Delivery Length 4325/1655mm
axle base(tracklength on ground) 1100mm
Upper width 990mm
Total height 2272mm
Standard track shoe width 180mm
track gauge 920mm
Minimum ground clearance 119mm
Tail turning radius 790mm
Track grounding length 1050mm
Track length 1545mm
Weight 1300KG
Bucket Capacity 0.02
Rated Power 10.2KW/2500RPM
Swing Speed 12RMP
Max. Grade Ability 30°
Max. digging height 2580mm
Max. dumping height 1637mm
Max. digging depth 2060mm
Max. digging distance 3160mm
Min. rotation radius 1711mm
Min. rotation radius Max height 2048mm
Engine KubotaD722
Valve China

Quick Detail:
1. Powerful Engine, KOOP diesel engine/Euro V engine/EPA certified gasoline /Kubota engine for your choices;


2. Adopt the famous hydraulic Shut-off valve;


3. The boom and the bulldozer oil cylinder are equipped with high-strength cast steel protective plates;


4. Dig-to-blade and dozer float features are easy to clean up;


5. Strong lift and dig performance helps you to get the job done faster;


6. Auger, grab, hydraulic hammer, and narrow bucket can be installed;


7. Hydraulic pilot operation is more flexible and convenient.


Applications:
The main uses of the excavator: in road construction projects to excavate trenches, in construction projects to excavate the foundation, in water conservancy projects to excavate ditches, canals, and dredging rivers, in quarries, open-pit mining and other projects for the stripping and excavation of ore, etc.; in addition to gravel, coal and other loose materials can be loaded.


Operation: After replacing the working device, it can also be used for lifting, pouring, installation, piling, ramming, and pile pulling.
Euro V Engine Bucket Wheel Excavator 1.6 Ton Construction Digger Machine
Euro V Engine Bucket Wheel Excavator 1.6 Ton Construction Digger Machine
Euro V Engine Bucket Wheel Excavator 1.6 Ton Construction Digger Machine

Our Service:

We support OEM/ODM service, and we have a professional development research department, designs, colors, and also products all can be acceptably customized, we have 3 times to supervise quality control through the production line before sending out. And quality and service is the first principle of the company. We keep 12 months warranty, beyond the warranty period, and all spare parts are offered to you at our cost price (not including freight). By the way, we support 24Hour customer service by email or phone. Please feel free to contact us, we are willing to become your friend and business partner.

Euro V Engine Bucket Wheel Excavator 1.6 Ton Construction Digger Machine

Euro V Engine Bucket Wheel Excavator 1.6 Ton Construction Digger Machine


FAQ
Q1: Are you original manufacturer?
We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.

Q2: What about the warranty time?
1 year or 2000 hours. We shoulder all costs during the warranty period, include the freight. And we also provide after-sales service support andagricultural technical support

Q3: What engine you can offer?
Optional Yanmar, Kubota, Brrigs&Sttraton engine,
Optional US EPA & Euro stage V engine

Q4: How can we ensure quality?
We have quality control sysmterm and also double check supervise team,
The final inspection is always carried out before shipment

Q5: What is your production time or delivery time?
Usually, we make merchandise inventory, if we have the products in stock, the delivery time is 5-10 days after receiving the deposit. If we don't have the products in stock, we will arrange the production right now, the delivery time will be 30-45 days,It depend on the order quantity.

Q6: What is your payment term?
Normally we can worked on T/T and support 30% payment in advanced and the other balance 70% can be paid against COPY B/L.

Q7: Do you support Customized service?
Yes, offer me necessary information, we provide custom-make service to meet different needs of global clients with different budgets.

Q8: Do you offer the accessories ?
Yes, we have many kinds of accessories for your choice and make the mini excavator in a wide usage and more effective.

Q9: How do you pack the machine if buy one unit?
Usually we pack the whole machine with the strong wooden crate.

Q10: What is your MOQ?
We support th small order and our MOQ is 1 unit
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
