Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
Specifications
Brand Name :
Sinowon
Model Number :
SU300C
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
50pcs
Delivery Time :
7-15days
Packaging Details :
carton
Model :
SU-330C
Code :
882-141C
Probe :
Standard 10N
Range :
HRC 20-68; HRB 55-100;HRA37-85
Description
Long Probe Ultrasonic Hardness Tester For reliable Hand-held HardnessTesting

--------------------Gear Hardness Tester, Deep Hole Hardness Tester---------------------------

Our manual measurement probes are available with test forces 10N, 20N. They are ideal for general, hand-held testing procedures in the fields of production and maintenance.

Manual measurement probes have been designed for daily use and will help you quickly achieve reliable results when manually measuring without guidance aids or stands.

Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting

Technical Specifications:

Name Extended Manual Probe Ultrasonic Hardness Tester
Model SU-330C
Code# 882-141C
Probe Standard 10N:HP-1C；Optional 20N:HP-2C
Range(DIN)

HRC:20-68；HRB:55-100；HRA:37-85；

HBS:100-500；HV:100-1500；Mpa:255-2180N/mm

Accuracy(%)

 Scale ﹤250HV 250~500HV 500~800HV ﹥800HV
HV0.1 6 7 8 9
HV0.3 6 7 8 9
HV0.8 5 5 6 7
HV1 5 5 6 7
HV5 5 5 5 5
HV10 5 5 5 5
Scales (HV)；(HRA,HRB,HRC);(HB)；(HS)
Screen 3.2“ Color LCD
Data Display

Loading force,Testing-times, Testing result, Average,

Maximum,Minimum,Deviation and Conversion scale.
Language Chinese, English, German, Portugese, Turkish
Data Output RS232 Hyper Terminal/Bluetooth Printer
Data Storage To save 1000-groups of measuring data and 20-groups of calibration data
Word Input Letters and numerals
Working Environment Temperature: -10°C to 50°C ; Humidity :30%-80% R.H.
Battery Voltage Rechargeable lithium battery ; Voltage :4.2V, 4800mAh
Recharger Voltage AC220V/50Hz, 110V/60Hz
Main unit Dimension and Weight Main unit Dimension :160 x 80 x 30mm (L x W x H);Manual Probe:Φ22×153mm ; Weight(No Probe): 0.5Kg
Packing Dimension and Weight Packing Dimension :320 x 430 x 155mm (L x W x H) ; Packing Weight (Standard Delivery):4.3Kg

Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting

Standard Delivery:

Product Name Code # Product Name Code # Product Name Code #
Instrument Main Body 882-141C 10N Manual Extended Probe 882-321C Anti Vibration Case 882-901
Standard Rockwell Block 882-641 Probe Cable 882-801 Screw 882-951
USB Recharger 882-851 COM Cable 882-810 Operation Manual SU-300H
Qualification Certificate SU-300H Packing List SU-300H Warranty Card SU-300H

Long Probe Ultrasonic Portable Hardness Tester For Reliable Hand Held HardnessTesting
