Horizontal LCD Touch Sceen Video Projector With Automatic Edge-detecting
Horizontal LCD Touch Sceen Video Projector With Automatic Edge-detecting
Horizontal LCD Touch Sceen Video Projector With Automatic Edge-detecting
Horizontal LCD Touch Sceen Video Projector With Automatic Edge-detecting
Specifications
Brand Name :
SINOWON
Model Number :
PH-3020
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Supply Ability :
100 sets per month
Delivery Time :
10 days
Packaging Details :
Plywood, 760×650×1760mm, Carton
X/Y-axis Travel :
　300×200mm
Repeatablitily :
±2um
Accuracy :
≤4+L/200(um)
Screen Dimension :
19' LCD Touch Screen Monitor
Sway Range :
±15°
Suitable Environment :
Workshop and metrology room
Dimension(D×W×H) :
760×650×1760mm
Net Weight :
200Kg
Measuring Software :
Quick Measuring 2.0
Description

Horizontal LCD Touch Sceen Video Projector With Automatic Edge-detecting

Specifications:

Model 　PH-3020
Code# 　541-321
X/Y-axis Travel 　300×200mm
Y-axis Travel 　200mm
Accuracy ≤4+L/200(um)
Repeatablitily ±2um
Operation Mode Manual
Sway Range ±15°
Video Device 1/3＂ color CCD camera,6.5x Detented zoom lens
Screen Dimension 19＇LCD Touch Screen Monitor
Video Magnification 30X～190X(it can extend to 15X～380X)
Working Distance 92mm
Measuring Software Quick Measuring 2.0
Max.Load Capacity 15Kg
Suitable Environment Workshop and metrology room
Dimension(D×W×H) 760×650×1760mm
Net Weight 200Kg

Standard Delivery:

Product Name

Code#

Product Name

Code#

Product Name

Code#

Measuring Software

581-111

Color CCD Camera

484-131

Detented Zoom Lens

421-111

Calibration Block

581-801

Capture Card 7130

527-131

LED Illuminator

425-101

19＂LCD Touch Screen

581-971

Built-in PC System

581-961

Operation Manual

PH Series

Characteristics:

1) Solid framework,large LCD touch screen and advanced QM2.0 software;

2) High quality optics for crisp and clear images;

3) Adjustable LED surface and contour illumination;

4) High resolution industrial CCD camera;

5) 6.5X Detented zoom lens changable within the range of 30-190x magnification

6) Easy to operate user interface;

7) Extended function of printing,saving and exporting data;

8) Excel,word or txt multi-format report output,and DXF input and output;

9) Non-contact optical height measurement;

10) Automatic edge-detecting function;

11) Make Save and input the program;

12) Map photo and measurement;

13) Dimension lable function;

14) SPC statistical function;
