Industrial Electronic Manual Micro Hardness Tester with Analogue Eyepice
Industrial Electronic Manual Micro Hardness Tester with Analogue Eyepice
Specifications
Brand Name :
Sinowon
Model Number :
HV-1000Z
Certification :
CE
Place of Origin :
China
MOQ :
1
Supply Ability :
100 SETS PER MONTH
Delivery Time :
10 days
Packaging Details :
plywood
Testing Force :
10gf,25gf,50gf,100gf,200gf,300gf,500gf,1000gf
Indentation Measurement :
Mechanic Micrometer
Loading Control :
Automatic (Loading,Dwell,Unloading)
Magnification on of Eyepice :
10x Analogue Eyepice
Dwell Time :
Adjustable 5~60s
Testing Range :
1HV~29667HV
Max,Height Of Specimen :
70mm
Instrument Throat :
95mm
Power Supply :
AC220/50HZ;110V/60HZ
Dimension :
425x245x490mm
Packing Dimension :
500x490x700mm
Gross/Net Weight :
45kg/35kg
Execution Standard :
ISO6507,ASTM E92,JIS 2244,GB/T4340
Description

Economical Manual Micro Hardness Tester with Analogue Eyepice and Manual Measurement


Characteristics:

● The micro hardness testing of materials allows for the determination of the hardness of small or thin specimens and small areas of larger specimens, Micro hardness testing is commonly used to determine characteristics of thin sheets, foils, fine wire, epoxies, paints, etc. and is often employed in R&D applications .
● Micro hardness is especially useful in determining hardness variations, caused by hardening, quenching, plating, fabrication, welding or annealing, bonding, etc. Micro hardness testing can be accurately employed using loads as slight as 1 gram, somewhat less and considerably more in certain situation.


Specifications:

duct Name

Auto-Turret Micro
Vickers Hardness Tester

Model

HV-1000Z

Code#

823-101Z

Loading Force

N

0.098,0.246,0.49,0.98,1.96,2.94,4.90,9.80

gf

10,25,50,100,200,300,500,1000

Indentation Measurement

Mechanic Micrometer

Loading Control

Automatic (Loading, Dwell, Unloading)

Magnification of Microscope

Observation:10x/40x; Measurement:10x/40x

Magnification on of Eyepiece

10x Analogue Eyepiece

Dwell Time

Adjustable 5~60s

Testing Range

1HV-2967HV

Analogue X-Y Anvil

Size:100x100mm; Travel:25 x25mm; Resolution:2um

Illumination

Adjustable LED light-source(Halogen is optional)

Max. Height of Specimen

70mm

Instrument Throat

95mm

Power Supply

AC220V/50Hz; AC110V/60Hz

Dimension(LxWxH)

425×245×490mm

Packing Dimension

500 x490 x700mm

Gross/Net Weight

45Kg/35Kg

Execution Standard

ISO 6507,ASTM E92,JIS Z2244,GB/T4340
















































Standard Delivery

Product Name

Code#

Product Name

Code#

Product Name

Code#

Vickers Indenter

823-401

Objectives 40x

823-341

Level Screw

823-931

Vickers Hardness Block HV 0.5

823-621

Objectives 10x

823-311

Anti-dust Cover

823-911

Vickers Hardness Block HV 1

823-611

X-Y Anvil

823-701

Accessories Box

823-901

10x Eyepiece

823-301

Power Cable

823-801

Instrument Manual

HV-1000/HV-1000Z


Optional Accessories:

Product Name

Code#

Product Name

Code#

Product Name

Code#

Vickers Measuring Software

823-461

Unequal Spencimen Clamp

823-741

X-Y Anvil

823-701

25mm Digital Micrometer Head
with Resolution 1 um

823-719

Filament Clamp

823-761

USB Camera USB-V1

823-471

6.8”LCD Video Monitor

823-821

Flat Precision Clamp

823-711

Video Measuring Camera

823-811

15x Digital Eyepiece

823-351

Thin-piece Clamp

823-751

1.5x Vickers CCD Adapter

823-361
