Rapid temperature change test chamber HTC-300- SC
Rapid temperature change test chamber HTC-300- SC
Specifications
Brand Name :
Hoyamo
Model Number :
HTC-300- SC
Certification :
CE
Place of Origin :
DONGGUAN/CHINA
MOQ :
1 Set
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100 Sets per Week
Delivery Time :
16 - 24 Days
Packaging Details :
Plywood Box, Dimensions Depends on Model
Power supply :
AC3∮，220/380V ,50/60HZ
Inner dimension :
580mm*750mm*765mm
Humidity range :
10%R.H~98%R.H
temperature range :
-40~+150℃
Description

Rapid temperature change test chamber HTC-300- SC

Rapid temperature change test chamber HTC-300- SC

Description:
The rapid temperature change test box is also known as the temperature cycle test box and the environmental stress screening (ESS) test box. It is suitable for environmental stress screening tests. Through the environmental stress screening of the products, the design defects of the products can be found quickly and the reliability of the products can be improved.

Feature:
Wide temperature area: large capacity test area
Sample temperature control: optional test temperature control function is available. Novel design: the design is more case-like and practical.

Rapid temperature change test chamber HTC-300- SCRapid temperature change test chamber HTC-300- SC

Specification:

Model HTH-300-SC HTH-600-SC HTH-990-SC HTH-300-SD HTH-600-SD HTH-990-SD
Inner dimension (W*H*D)mm 580*750*765 800*950*800 1100*950*950 580*750*765 800*950*800 1100*950*950
External dimension (W*H*D)mm 880*1730*1570 1000*1950*1900 1400*1950*2100 880*1730*1570 1000*1950*1900 1400*1950*2100
Internal volume(L) 300 600 990 300 600 990
Temperature range -40~+150℃ -60~+150℃
Heating rate 5℃/min,10℃/min Linear (can be customized)
Cooling rate 5℃/min Linear grid (customizable)
Temperature fluctuation ±0.5℃ (No-load state)
Temperature deviation ±2.0℃ (No-load state)
Temperature uniformity ±2.0℃ (No-load state)
Humidity range 10%R.H~98%R.H
Temperature change rate

Heating rate : Not less than 5.0℃, 10℃/min (-55~85℃ the whole process average )

Cooling rate : Not less than 2.0℃ /min (+85~-55℃ the whole process average)
cooling Air-cooled (or water-cooled)
Product tags

cme temperature chamber

,

high and low temperature test chamber

,

low temperature test chamber
