QKX-72 High Accuracy Temperature Control Industrial Drying Chamber with SUS304 Stainless Steel
QKX-72 High Accuracy Temperature Control Industrial Drying Chamber with SUS304 Stainless Steel
Specifications
Brand Name :
SINOWON
Model Number :
QKX-72
Certification :
CE
Place of Origin :
DONGGUAN/CHINA
MOQ :
1 Set
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
120 Sets per Month
Delivery Time :
16 - 24 Days
Packaging Details :
Plywood Box, Dimensions Depends on Model
Control System :
Hot air circulation control mode
Temp. range :
RT - 260 Deg C (Available to 500 Deg C)
Temp. uniformity :
1.5 Deg C by Chamber Dimension
Interior material :
SUS304# mirror stainless steel
Description
QKX-72 High Accuracy Temperature Control Industrial Drying Chamber with SUS304 Stainless Steel

QKX-72 High Accuracy Temperature Control Industrial Drying Chamber with SUS304 Stainless Steel

Bench-top forced air oven is designed to meet both manufacturing and laboratory requirements. Our standard ovens are in stock and ready to ship.


Features:

※ Oven exterior material is high quality Cold Rolled Steel with surface treatment, nice appearance and durable.

※ Interior material is SUS304# mirror stainless steel with excellent heat resistance and easy to clean.


※ Unique combination of bottom scattered wind and heater, centrifugal turbine cycle effectively extend using life of fan.


※ Temperature uniformly distributed in the interior chamber, loop fan is automatically closed after temperature reaches setup.


※ With over-heat protection switch and power off memory function


※ The Ovens are widely used in kinds of composite materials, like electric parts, rubber, plastics, aerospace and automotive industries, etc.


※ Custom made maximum temperature range from room temperature to 500℃.


※ Vacuum oven is available according to specific applications.

Specifications:

Model

QKX-72

QKX-150

QKX-270

QKX-1000

QKX-540

Interior dimensions

mm

W

450

500

600

1000

900

H

400

600

900

1000

1200

D

400

500

500

1000

500

Exterior dimensions

mm

W

660

750

830

1200

1090

H

820

1160

1580

1600

1800

D

520

620

680

1200

670

Power

AC380V, 50/60HZ, Three-phase (Specified by User)

Control System

Hot air circulation control mode

Ambient temp. & humid. Range

+5℃ ~ +35℃ / <85%RH

Temp. range

RT+20℃~300℃(The maximum operating temperature recommend ≤260℃)

Heating up time

RT~100℃within 10 min

Temp. uniformity

±1.5℃

Temp. constancy

±0.5℃

Temp. accuracy

±0.1℃

Interior material

SUS304# mirror stainless steel

Exterior material

high quality Cold Rolled Steel with surface treatment

Insulation

Glass wool

Safety devices

Overheat protector, Magnetic switch, Porcelain fuse, Alarm system

Accessories

Adjustable Shelf 2pcs, Overheating protective device
