■ Product Feature
▶ Temperature detection, face recognition and hand disinfection were carried out simultaneously.
▶ Hand infrared sensor, disinfectant intelligent quantitative liquid refining spray.
▶ Intelligent induction, zero contact to avoid the risk of cross-infection.
▶ The disinfectant sprayer is made of ABS material, which is environmental protection and safe, corrosion resistant, insulating current and not easy to deform.
▶ Hand sterilizer 10L large capacity tank, long-term use, easy to change the disinfectant.
■ Product Overview
▶ High-performance, high-reliability, and high-stability Android system
▶ Cutting-edge deep learning algorithm used as the core
▶ Standard local 20,000 faces database, face recognition accuracy > 99.97%, recognition speed < 100 ms
▶ Binocular living anti-counterfeiting, preventing photo and video deceptions
▶ 8-inch A-gauge LCD, projected and capacitive touch screen technology, and full-screen operation interface
▶ Adopt 2 million intelligent wide dynamic sensor face recognition camera
▶ 2 million intelligent wide dynamic sensor, which supports strong light, backlight, and dark complex light environments
▶ Body temperature measurement, temperature display, and automatic alarm generation for abnormal temperatures
▶ Infrared and TGB double light compensation, and weak light identification without interference
▶ Optional wired/Wi-FI/4G communication
▶ Multi-language broadcasting
■Product Specifications
Model | LKS-TM002SF |
Operating system | Android 7.1.2 |
Camera | 2 million wide dynamic, live dual cameras, strong backlight resistance |
Touch screen | Capacitive touch screen, 8-inch A-gauge LCD (16:10) |
Display resolution | 1280 x 800 |
Camera resolution | 1280 x 720 |
CPU | Quad core RK3288 ARM-A17 1.8GH,GPU:Mail-T764 |
Storage | Memory: 2G Storage: 8G |
Authentication mode | Face recognition, temperature measurement |
Measurement range | 35.5℃—42℃(Non-medical product features) |
Temperature measurement accuracy | Accuracy:0.5℃ Face Distance:30CM—50CM |
Storage capacity | 20,000 faces database and 150,000 records |
External interface | USB RJ45 RS232 TTL reset switch, Wi-Fi antenna interface Brake machine interface |
Operating voltage | 12 V DC ±10% |
Communication mode | Wired network, Wi-Fi, optional 4G |
Hand disinfection | Spray disinfectant |
Spray trigger mode | Infrared induction, induction distance adjustable, strong anti-interference, not afraid of light changes, not affected by skin color |
Disinfectant capacity | 10L refillable inner bottle |
Spray pump head | Service life more than 300,000 times |
External Size | 340(width)×1600(high)×320(thickness)mm |
shell material | Cold rolled steel plate material |
Installation mode | vertical bracket |
FAQ
Q1: Are you a factory?
A: Yes, we are a manufacturer of ticket vending kiosks, parking lot equipment, payment kiosks, self-service terminals, and so on.
Q2: Do you accept OEM or ODM orders?
A: Yes, we welcome OEM and ODM orders.
Q3: Could you offer wholesale price?
A: Yes, of course. If you order large QTY, we can give you the bulk price.
Q4: I'm shopping at your company for the first time, how can I trust you?
A: If you have questions about our first cooperation, we fully understand. You are welcome to visit our company or our factory at any time.
Q5: I'm looking for some products which is not shown on your website, can you make me the special order?
A: We value the cooperation between us. Therefore, if you have a demand, we will be happy to provide you with a complete solution..
Q6: How to shipping my order?
A: We have strong cooperation with DHL, UPS, FedEx, EMS, TNT, China Air Post. You also can choose your own shipping forwarder.
Q7: How to be your agent in my country?
A: You must plan to build a long-term relationship with us. Authorization will depend on your purchase volume and the expected size of the regional market.
