Vertical Display ip video wall controller Support large - screen image freeze
Vertical Display ip video wall controller Support large - screen image freeze
Vertical Display ip video wall controller Support large - screen image freeze
Vertical Display ip video wall controller Support large - screen image freeze
Specifications
Place of Origin :
SHENZHEN,CHINA
Brand Name :
DDW
Certification :
CE,CB
Model Number :
DDW-VPHXXXX
MOQ :
1 pcs
Price :
Negotiable
Packaging Details :
Double layer carton pack
Delivery Time :
3working days upon payment
Payment Terms :
T/T,L/C,Western Union,Alibaba Trade Assurance
Supply Ability :
1000pcs/month
Description

Input Output HDMI DIV VGA AV ypbpr data path x4 - video wall controller


It has following key features:
1 . Support large-screen image freeze

2 . Support open-window effects processing

3 . Flexibility to increase the input/output board
4 . Real time image display, no dropped frames

5 . Full hardware configuration without operating system

6 . Support partial input and output cards with mixed interpolation
7 . Redundant power supply design, thermostatically controlled fan
8 . Input/output card supports hot-swappable, plug-and-play functionality
9 . Support display at arbitrary position, at any size and any superimposed
10 . High-speed bus parallel processing technology, high-bandwidth uncompressed processing
11 . Support memory card or network transmission ultra-high-definition pictures, peer-to-peer ultra-high-definition mosaic wall background image
12 . Chassis backplane + plug-in configuration, excellent performance for radiating, anti-dust chassis, equipped with replaceable air filter can be stable for a long time, even in harsh environments

DDW Lcd video wall controller is one of professional modularized and hardware Lcd video wall processor which supports HDMI,DVI,VGA,AV,YPBPR, each channel support 1920x1200 resolution signal inputs and outputs,RS232 and IP control method.

Vertical Display ip video wall controller Support large - screen image freeze

Parameters:

Technical Specifications
Model series With CBD No CBD
Function description 4channel CBD,16channel AV, 12channel VGA/DVI input, 6U case supports 12 screens arrays, compatible with ultra-high resolution 4000/(8000)x2000 Dynamic background image 16channel AV,16channel VGA/ DVI input,6U case supports 16screens arrays
Input signal(optional) HDMI/DVI/VGA/AV/YPbPr
Input resolution 1024x768~1080p,commonly used resolutions
Output signal format DVI/VGA/AV/YPbPr/HDMI(DVI-HDMI converter)
Output resolution Up to 1920x1200/60HZ
System control software Special control software
Power Supply Redundant power supply 110-220VAC, 50/60Hz
Consumption 12W/channel
Working temperature -20°C——60°C
Working Humidity 5-95%
Case specification 4U/6U/10U/15U standard rackmount chassis
Serial Control Interface RS-232,9-pin female, Type-D
Baud Rate 115200
Pin configuration 2=TX,3=RX,5=GND
Ethernet control interface RJ-45 female, TCP/IP
Ethernet control speed Auto 10M or 100M,Full-duplex or half-duplex
Working time 365 x 7 x 24hrs
Technical specification of input/output connectors
VGA/RGB input Input: 15pin HD D-Sub, female
Sync mode: HV independent sync
Color Depth: 32bit/pixel
Resolution: 640 x 480/60HZ—1920 x1200/60HZ
Input impedance :75Ω
Video input Input connector: BNC
Detecting: full-format auto detecting
Input impedance :75Ω
VGA or DVI output Resolution:1024 x 768/60HZ-1920 x 1200/60HZ
Color depth: 32bit/pixel
Output impedance:75Ω
Physical properties of input/output connectors
Signals Connectors Type
Composite VIDEO input BNC female
VGA input 15 pin HD D-Sub female
VGA output 15 pin HD D-Sub female
DVI output 24+5 or 24+1 standard female
AUX RS-232 9-pin D-Sub female
Main RS-232 9-pin D-Sub female

Vertical Display ip video wall controller Support large - screen image freeze
