MachineU > China Products > Service Equipment > Digital Signage > Digital Signage and Displays
Security Narrow Bezel Video Wall 500nits Digital Signage Screen with LED Backlit
Security Narrow Bezel Video Wall 500nits Digital Signage Screen with LED Backlit
Security Narrow Bezel Video Wall 500nits Digital Signage Screen with LED Backlit
Security Narrow Bezel Video Wall 500nits Digital Signage Screen with LED Backlit
Specifications
Brand Name :
XUNSHINA
Model Number :
XS460-5500HD-LNL4
Certification :
CE/ROHS/FCC
Place of Origin :
China
MOQ :
4pcs
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
3000pcs per month
Delivery Time :
3-7 working days after payment
Packaging Details :
Inner package: honeycomb carton with EPE foam full covering, Outer package: 4 in 1 plywood case
Brightness :
500 nits
Width :
3.5mm bezel
Resolution :
1920*1080
Display color :
1.07B
Dimension :
1213.4mm(W) x684.2mm(H) x109.4mm(D)
Power consumption :
130 watt
Description

Security Narrow Bezel Video Wall 500nits Digital Signage Screen with LED Backlit

Description of lcd video wall
1.RS232 remote control, each unit can be looped out.
2.LCD product itself with low power consumption and last much longer.
3.Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.

Specifications

Model No. XS460-5500HD-LNL4

LCD

 Size 55" LG panel
Resolution 1920(H)x1080(V)
Pixel pitch 0.630(H)x0.630(V)
Backlight LED
Brightness(typical) 500cd/m²
Contrast 1400 : 1
Viewing angel (H/V) 178° / 178°
Color depth 1.07B (10bit)
Response time <8ms
Display area 1209.8(H)×680.4(V)
Bezel 3.5mm

Interface

 CVBS In / Out (BNC ) 1/1
VGA In / Out 1/0
DVI In / Out 1/0
HDMI In/Out 1/0
DEBUG(USB) 1/0
Control IR remote control Yes
RS-232 In/Out 1/2

Physical parameter

 Dimension

1213.4mm(W) x684.2mm(H) x109.4mm(D)
Frame color Black
Frame material Metal
Net weight 30Kg

Power

 Power consumption ≦130W
Standby <1W
Power supply AC 100V-240V, 50/60Hz,Universal,±10%

Environment

 Operating humidity 20-90% RH(no condensation)
Storage humidity 10-90% RH (no condensation)
Operating temperature 0 ~ 50° C / 32 ~ 122° F
Storage temperature -20 ~ 60° C / -4 ~ 140° F

Accessory

 Standard accessories Power cable, User manual, Warranty card, Quality certificate
Optional accessories Wall mounted brackets, floor stand brackets, cabinet
*design and specifications are subject to changes without prior notice

Applications

1.Education and Conference System
2.Safety Monitoring System of Mining and Energy Industry
3.Commercial Industry
Used in the display terminal of commercial industry, such as advertising, media, product presentations
4.Financial Industry
Used in the information display terminal of financial industry, such as stock and security market. .
5.Transportation Industry
Used in the information display terminal of transportation industry, such as airports, ports, metro, highway.
6.Management and Control System
Used in the display terminal of management and control system such as fire-fighting, meteorology, maritime, food prevention, transportation hub
