3.2 Meter Automatic Digital Textile Printer For Bedding / Curtain / HomeTextile

3.2m large format digital textile printer for beding / curtain / home textile

• Printhead type:Kyocera KJ4B-QA06
• High speed:270m2/h,1200*1200dpi
• Print fabric width:0-3200mm
• Output: 2000m/day
• Ink type:reactive,disperse,acid,pigment

A. Main specifications:

B. Description:

1) Features:

• High speed and quality printing:270m2/hour.
• 8 color configuration,reactive,acid,disperse and pigment ink applicable.
• Multifunctional cleaning device for print heads cleaning,sealed moisturizing and waste ink disposal.
• Independent motion system,ink system and printing system,high stability.

2) Ink for fabric:

- Acid inks – on polyamide Lycra, wool, silk

- Pigment ink - any kind of fabric

- Reactive inks – on all natural fibers such as cotton,silk,wool,etc

- disperse inks – directly onto polyester and blends

3) Performance:

4) Main parts & systerm:

• Printhead:Kyocera Japan
• Rip Software:TEXPRINT
• Servo motor Japan Panasonic& speed reducer German .
• Fabric transportation: SwissHabasit industrial belt.
• Germany printhead moving guider .
• Machine body ,operating platform
• Printing control and operating system
• Ink supply system
• Belt cleaning systerm
• Fabric feeding and taking up systerm
• Transducer & photoelectric sensor system, while fabric not flat or upwarp , it will alarm,and printhead will stop working.One set of this system installed beside belt, another one beside printhead.
• Belt-transporting system,integrated fabric feeding & take-up system,fabric spreading , fabric entry unit.
• Belt cleaning system:Auto brush & sponge-roller washing system belt wiping system.
• Ink supply:peristaltic pump supply,degassing NEG pressure system

5) The Advantages of RIP software

• Accurately control the ink volume when printer work, so that the printed image exactly as same as the designs prepared
• Freely adjust the brightness, contrast, etc by RIP according to your request

C. Our service:

1) Before place order:

We provide a suitable project according to your environment and production capacity.

2) Installation training service:

We dispatch technician to your factory for installation ,testing and training.

3) Quality Guarantee:

The whole set of machine guarantee is 1 year. The print head is half year.We offer flexible extended

warranties if needed.

D. Enviroment request:

1) Temperature is generally controlled at 15~30 ℃ and Humidity at 50%~70%.

2) The machine should be protected from direct radiation of sunshine, strong light, wind or heat source.

3) The surrounding of the machine should be left with sufficient space for normal ventilation.
